OTR tyres

Off-the-road tyres,130 patterns, sizes on request.

130 patterns for mining, earthmoving, underground, port and industrial, agricultural and special machines. Radial and bias, with size, TRA code, load, rim and dimensions for each.

Send a request Talk to us on WhatsApp

Free to ask · Confidential · Everything in writing

Classification

How OTR tyres are coded.

The TRA code tells you the machine and the tread depth. Choose it with the size and the load.

Code	Machine	Tread
C	Compactor	Smooth
E2, E3, E4	Earthmover (dump truck, scraper)	Traction, rock, rock deep tread
L2, L3, L4, L5	Loader and dozer	Traction, rock, rock deep, rock very deep tread
G2	Grader	Traction
Stars or PR	Load strength of the casing	More stars or plies, higher load

Catalogue

All patterns and sizes.

Typical values from the catalogue. Every order is confirmed by the supplier in writing.

Download the OTR catalogue (PDF, 26 MB)

The full catalogue is available as a PDF.

Mining and earthmoving

MA01

Construction: All steel radial
TRA: E3, L3
Stars: **
TT/TL: TL
Applications: wheel loader, dump truck, grader

All steel radial construction; improved protector plies optimise load performance and operator comfort; high-tech casing reduces heat build up; E3/L3 non-directional tread gives superior traction in soft underfoot.

Sizes (6)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5R25	E3	167B	5450	5.25	14.00/1.5	1346	457	27
17.5R25	L3	180A2	8500	6.5	14.00/1.5	1346	457	27
20.5R25	E3	177B	7700	5.25	17.00/2.0	1475	555	31
20.5R25	L3	193A2	11500	6.5	17.00/2.0	1475	555	31
23.5R25	E3	188B	9250	5.25	19.50/2.5	1625	699	35
23.5R25	L3	201A2	14500	6.5	19.50/2.5	1625	699	35

MA01+

Construction: All steel radial
TRA: E3, L3
Stars: **
TT/TL: TL
Applications: wheel loader, dump truck, grader

All steel radial construction; improved protector plies and high-tech casing reduce heat build up; proven E3/L3 tread optimised for a wide range of challenging construction and quarry applications.

Sizes (10)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5R25	E3	167B	5450	5.25	14.00/1.5	1550	465	27
17.5R25	L3	182A2	8500	6.5	14.00/1.5	1550	465	27
20.5R25	E3	177B	7300	5.25	17.00/2.0	1460	520	33
20.5R25	L3	193A2	11500	6.5	17.00/2.0	1460	520	33
23.5R25	E3	188B	9250	5.25	19.50/2.5	1615	595	36
23.5R25	L3	201A2	14500	6.5	19.50/2.5	1615	595	36
26.5R25	E3	197B	11200	5.25	22.00/3.0	1760	675	37
26.5R25	L3	216A2	18200	6.5	22.00/3.0	1760	675	37
29.5R25	E3	208B	14000	5.25	25.00/3.5	1875	750	45
29.5R25	L3	218A2	23600	6.5	25.00/3.5	1875	750	45

MA02

Construction: All steel radial
TRA: E3+, L3+
Stars: **
TT/TL: TL
Applications: wheel loader, dump truck, scraper, grader

All steel radial construction; improved protector plies and high-tech casing; excellent traction in all off-road applications with thick undertread for improved puncture resistance.

Sizes (6)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
23.5R25	E3+	185B	9250	5.0	19.50/2.5	1615	598	41
23.5R25	L3+	201A2	14500	6.5	19.50/2.5	1615	598	41
26.5R25	E3+	193B	11500	5.0	22.00/3.0	1754	686	41
26.5R25	L3+	209A2	18500	6.5	22.00/3.0	1754	686	41
29.5R25	E3+	200B	14000	5.0	25.00/3.5	1880	737	44
29.5R25	L3+	216A2	22350	6.5	25.00/3.5	1880	737	44

MA02F

Construction: All steel radial
TRA: E3+
Stars: **
TT/TL: TL
Applications: dump truck, wheel loader, grader

All steel radial construction; high-tech casing reduces heat build up; durable and aggressive E3+ open tread design grips in the most demanding surfaces.

Sizes (3)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
29.5R29	E3+	202B	15000	5.25	25.00/3.5	1990	770	50
33.25R29	E3+	209B	18500	5.25	27.00/3.5	2065	860	45
37.25R35	E3+	218B	23600	5.25	31.00/4.0	2360	940	47

MA02+

Construction: All steel radial
TRA: E3+, L3+
Stars: **
TT/TL: TL
Applications: wheel loader, dump truck, grader

All steel radial construction; high-tech casing reduces heat build up; E3+/L3+ self-cleaning tread design provides excellent traction and stability on the most demanding surfaces.

Sizes (4)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
750/65R25	E3+	190B	10000	4.25	24.00/3.0	1585	740	40
750/65R25	L3+	201A2	15000	4.75	24.00/3.0	1585	740	40
875/65R29	E3+	203B	15500	4.25	27.00/3.0	1860	860	48
875/65R29	L3+	234A2	21200	4.75	27.00/3.0	1860	860	48

MA60

Construction: Radial
TRA: E3, L3
Stars: **
TT/TL: TL
Applications: dump truck

Radial E3/L3 long-lasting tread for maximised productivity and reduced long-term operating costs; special rubber compound and robust casing resist damage; innovative tread lugs and grooves give forward and lateral traction and operator comfort.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
850/65R29 33.25R29	E3	269B	18500	5.25	27.00/3.5	2090	845	50
850/65R29 33.25R29	L3	282A2	29000	6.50	27.00/3.5	2090	845	50

M-TERRAIN

Construction: All steel radial
TRA: E4, L4
Stars: **
TT/TL: TL
Applications: dump truck

E4/L4 tread pattern tyre for all terrain; all steel radial construction; excellent traction and safety; multi-edged blocks offer improved flotation and super traction.

Sizes (12)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
20.5R25	E4	177B	7500	5.25	17.00/2.0	1490	520	48
20.5R25	L4	183A2	11500	6.5	17.00/2.0	1490	520	48
23.5R25	E4	188B	9250	5.25	19.50/2.5	1615	595	51
23.5R25	L4	193A2	14500	6.5	19.50/2.5	1615	595	51
26.5R25	E4	197B	11500	5.25	22.00/3.0	1800	675	54
26.5R25	L4	204A2	18500	6.5	22.00/3.0	1800	675	54
29.5R25	E4	206B	14000	5.25	25.00/3.5	1875	750	59
29.5R25	L4	216A2	22400	6.5	25.00/3.5	1875	750	59
750/65R25	E4	196B	10000	5.25	24.00/3.0	1610	714	55
750/65R25	L4	209A2	18500	6.5	24.00/3.0	1610	714	55
875/65R29	E4	203B	15500	5.25	28.00/3.5	1875	879	59
875/65R29	L4	221A2	23750	6.5	28.00/3.5	1875	879	59

M-TERRAIN+

Construction: All steel radial
TRA: E4, L4
Stars: **
TT/TL: TL
Applications: dump truck

E4/L4 tread pattern tyre for all terrain; all steel radial construction; excellent traction and safety; multi-edged blocks offer improved flotation and super traction.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
375/65R29	E4	195B	12150	4.25	24.00/3.5	1765	770	56
375/65R29	L4	231A2	23600	8.25	24.00/3.5	1765	770	56

MB450

Construction: Bias (cross-ply)
TRA: L4
TT/TL: TL
Applications: wheel loader

Heavy duty bias ply tyre with rock pattern in a nondirectional tread design; long lasting compound resists cutting, chipping and heat buildup; wide base sizes give traction and flotation.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5-25	L4	172A2	7300	4.7	14.00/1.5	1360	400	47

MA04+

Construction: All steel radial
TRA: E4
Stars: ** / ***
TT/TL: TL
Applications: dump truck, rigid dump truck

All steel radial construction; high-tech casing reduces heat build up; E4 pattern and aggressive lug design with large blocks at tread centre provides traction and braking on rough surfaces.

Sizes (9)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00R25	E4	169B	5800	7.0	10.00/1.5	1420	375	38
16.00R25	E4	180B	8000	8.0	11.25/2.0	1550	450	44
18.00R25	E4	189B	10300	7.0	13.00/2.5	1675	500	51
18.00R33	E4	191B	10900	7.0	13.00/2.5	1875	500	54
18.00R33	E4	195B	12150	8.0	13.00/2.5	1875	500	54
21.00R33	E4	200B	14000	7.0	15.00/3.0	1955	570	54
21.00R35	E4	204B	16000	8.0	15.00/3.0	2005	570	61
24.00R35	E4	209B	18500	7.0	17.00/3.5	2175	655	65
24.00R35	E4	212B	20000	8.0	17.00/3.5	2175	655	65

MA04+ GIANT

Construction: All steel radial
TRA: E4
Stars: **
TT/TL: TL
Applications: rigid dump truck

All steel radial construction; aggressive extra deep tread pattern offers long and even tread wear, a cooler running design and improved traction.

Sizes (7)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
27.00R49	E4	223B	27250	6.5	19.50/4.0	2690	740	82
33.00R51	E4	235B	38750	6.5	24.00/5.0	3030	920	95
37.00R57	E4	246B	53000	7.25	27.00/6.0	3440	1050	99
40.00R57	E4	250B	60000	7.25	29.00/6.0	3560	1130	99
46/90R57	E4	252B	63000	7.0	29.00/6.0	3560	1180	98
50/80R57	E4	257B	73000	6.0	34.00/5.0	3620	1266	95
59/80R63	E4	268B	100000	6.0	44.00/5.0	4026	1480	88

M-ROCK

Construction: All steel radial
TRA: E4
Stars: **
TT/TL: TL
Applications: rigid dump truck

All steel radial construction; E4 tread improves wear resistance and reduces internal friction and uneven wear; deep non-directional E4 pattern gives traction and protection against cuts and damages.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
27.00R49	E4	223B	27250	7.0	19.50/4.0	2688	710	68

M-RIGID

Construction: All steel radial
TRA: E4
Stars: ** / ***
TT/TL: TL
Applications: rigid dump truck

All steel radial construction; high-tech casing reduces heat build up; deep non-directional E4 tread gives traction and protection against cuts and damages.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
27.00R49	E4	223B	27250	7.0	19.50/4.0	2694	755	82
33.00R51	E4	226B	30000	8.0	24.00/5.0	3153	925	95

MA09+

Construction: All steel radial
TRA: E4
Stars: **
TT/TL: TL
Applications: rigid dump truck

All steel radial construction; high-tech casing reduces heat build up; deep E4 tread provides resistance to cutting, chipping and shock damage and enhances tyre life.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
30.00R51	E4	230B	33500	6.5	22.00/4.5	2878	845	75
36.00R51	E4	241B	46250	6.5	26.00/5.0	3194	990	83

MA06

Construction: All steel radial
TRA: E4
Stars: **
TT/TL: TL
Applications: rigid dump truck

All steel radial construction; high-tech casing reduces heat build up; tread pattern protects against tears, wear and cuts while providing stability, comfort and traction.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
40.00R57	E4	229A2	100000	8.0	29.00/6.0	3594	1097	87
40.00R57	E4	229A2	60000	7.0	29.00/6.0	3594	1097	87

MB10

Construction: Bias (cross-ply)
TRA: L5
TT/TL: TL
Applications: wheel loader

All cross-ply construction; improved protector plies and high-tech casing reduce heat build up; extra deep L5 tread pattern for excellent traction in the most severe circumstances.

Sizes (3)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
20.5-25	L5	184A2	9500	4.5	17.00/2.0	1550	520	79
23.5-25	L5	198A2	12100	4.75	19.00/2.5	1675	595	84
26.5-25	L5	209A2	15500	4.75	22.00/3.0	1800	675	91

M-DESERT

Construction: Bias (cross-ply)
TRA: E7
TT/TL: TL
Applications: dump truck

All cross-ply construction; high-tech casing reduces heat build up; E7 tread pattern protects against tears, wear and cuts while providing stability, comfort and traction.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
21.00-25	E7	186A2	9500	4.25	25.00/3.0	1654	628	15
26.5-25	E7	188B	18000	2.5	25.00/3.5	1830	750	23.5

MR500

Construction: Steel belted radial
TRA: IND
TT/TL: TL
Applications: wheel loader, wheeled excavator, dump truck

Steel belted radial tyre with improved protector plies; deep tread and traction pattern with excellent self-cleaning properties.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
440/70R24(17.5LR24)	IND	159B	4375	4.0	15.00	1254	455	32

MA11

TRA: E2, L2
Stars: **
TT/TL: TL
Applications: wheel loader

New tread compound reduces heat build-up at higher speeds; reinforced sidewall protection rib; aggressive non-directional tread for superior traction in soft underfoot conditions.

Sizes (6)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
365/70R18	E2	119B	2160	3.75	11.00	974	358	18
365/70R18	L2	144A2	3000	3.75	11.00	974	358	18
405/70R18	E2	141B	2575	3.75	13.00	1029	400	19
405/70R18	L2	153A2	3450	3.75	13.00	1029	400	19
405/70R20	E2	149B	2725	3.75	13.00	1090	400	19
405/70R20	L2	153A2	3875	3.75	13.00	1090	400	19

MB250

Construction: Bias (cross-ply)
TRA: IND
TT/TL: TL
Applications: wheeled excavator

Traction pattern with excellent self cleaning properties; all cross-ply construction; extra-deep tread and strong nylon carcass for puncture resistance and increased tyre life.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
15.5/80-24	IND	153A6	4875	4.0	W13	1202	393	35
15.5/80-24	IND	151A6	3450	4.0	W13	1202	393	35

MB400

TRA: IND
TT/TL: TL
Applications: wheel loader, wheeled excavator, backhoe loader

New improved technology of the high-tech casing reduces heat build up; pattern provides superior strength and a longer tread life.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
10.5/80-18	IND	123A6	1530	4.9	W9	881	274	25
12.5/80-18	IND	144A8	2815	4.9	W9	975	295	25

MB410

TRA: IND
TT/TL: TL
Applications: dump truck, excavator, wheel loader

High-tech casing reduces heat build up; modified tread pattern for excellent traction and flotation in soft underfoot conditions.

Sizes (5)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5L-24	IND	144A8	2995	2.6	15.00	1243	445	27
19.5L-24	IND	153A8	5450	2.5	17.00	1514	493	30
21L-26	IND	156A8	4003	2.5	16.00	1635	467	29
16.9-28	IND	151A8	3470	3.5	15.00	1609	439	36
16.9-30	IND	147A8	2670	2.7	15.00	1490	439	28

MB260

Construction: Bias (cross-ply)
TRA: IND
TT/TL: TL
Applications: wheeled excavator, wheel loader

High-tech casing reduces heat build up; all cross ply construction with improved load performance; deep non-directional tread pattern for increased traction.

Sizes (4)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
405/70-24 (16/70-24)	IND	149B	3250	3.5	13.00	1075	410	25
405/70-24 (16/70-24)	IND	164A2	5100	4.5	13.00	1075	410	25
405/70-24 (21/70-24)	IND	158B	3350	3.5	13.00	1175	410	30
405/70-24 (21/70-24)	IND	168A2	5600	4.5	13.00	1175	410	30

MB100

Construction: Bias (cross-ply)
TRA: IND
TT/TL: TT
Applications: wheel loader

All cross ply construction; massive lugs reinforced and connected to an extra thick centre tread rubber belt; aggressive traction pattern with excellent self cleaning properties.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
24.00-20	16	146B	3800	7.5	7.50	1655	278	22

MB210

Construction: Bias (cross-ply)
TRA: IND
TT/TL: TL
Applications: grader

All cross ply construction; massive lugs reinforced and connected to an extra thick centre tread rubber belt; aggressive traction pattern with excellent self cleaning properties.

Sizes (6)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
13.00-24	12	149A8	2725	5.0	8.00TG	1280	335	23
13.00-24	12	164A2	5600	4.5	8.00TG	1280	335	23
14.00-24	16	155A8	5650	5.5	8.00TG	1350	360	29
14.00-24	16	173A2	7500	5.5	8.00TG	1350	360	29
16.00-24	16	160A8	4260	5.0	10.00WA	1440	435	29
16.00-24	16	183A2	8250	4.25	10.00WA	1440	435	29

MA03

Construction: All steel radial
TRA: E2
Stars: ***
TT/TL: TL
Applications: mobile crane

All steel radial construction with improved protector plies; aggressive, self-cleaning tread design provides excellent traction in severe off-road conditions.

Sizes (5)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
385/95R24	E2	170E	6000	10.0	10.00W	1372	436	35
385/95R25	E2	170F	6000	9.0	10.00/1.5	1372	436	35
445/95R25	E2	174F	6700	9.0	11.25/2.0	1499	452	36
525/80R25	E2	176F	7300	7.0	13.00/2.5	1498	533	31
505/95R25	E2	180E	9500	10.0	13.00/2.5	1583	462	35

MA03+

Construction: All steel radial
TRA: E2
Stars: ***
TT/TL: TL
Applications: mobile crane

All steel radial construction with improved protector plies; tread design provides excellent traction in severe off-road conditions.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
385/95R25	E2	178F	6000	9.0	20.00/1.5	1599	579	24
445/95R25	E2	174F	6700	9.0	11.25/2.0	1498	435	28

AG23

Construction: Radial
TT/TL: TL
Applications: trailer

Radial construction for optimised load performance, low rolling resistance and operator comfort; transversely positioned rounded shoulder cleats optimise self-cleaning and rolling under severe conditions.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
24R35		176F			18.00	1580	650	17

E3/L3(W1), E3/L3(W2), E3/L3(N1), E3/L3(TH388)

TRA: E3, L3
Applications: wheel loader

Size table of E3/L3 pattern OTR tyres (W1, W2, N1, TH388 variants), 6.50-16 to 29.5-25, with max load and inflation pressure at 10 km/h and 50 km/h.

Sizes (37)

Size	TRA	Load (kg)	Rim	O.D. (mm)	S.W. (mm)
6.50-16	PR 10	/ (10 km/h)	5.50F	761	185
7.50-16	PR 10	/ (10 km/h)	6.00G	805	215
9.00-16	PR 14	/ (10 km/h)	6.50H	890	255
12.00-16	PR 16	/ (10 km/h)	8.50H	840	240
12.5/70-16	PR 14	2240 (10 km/h)	10	848	316
16/70-20	PR 18	5800 (10 km/h)	13	1075	410
16/70-20	PR 16	5150 (10 km/h)	13	1075	410
16/70-24	PR 16	5600 (10 km/h)	13	1175	410
20.5/70-16	PR 16	/ (10 km/h)	8.50H	1075	410
15.5-25	PR 16	6500 (10 km/h)	12.00/1.3	1275	395
17.5-25	PR 16	7300 (10 km/h)	14.00/1.5	1350	445
17.5-25	PR 20	8250 (10 km/h)	14.00/1.5	1350	445
20.5-25	PR 20	9500 (10 km/h)	17.00/2.0	1490	520
20.5-25	PR 24	10300 (10 km/h)	17.00/2.0	1490	520
23.5-25	PR 20	10900 (10 km/h)	19.50/2.5	1615	595
23.5-25	PR 24	10900 (10 km/h)	19.50/2.5	1615	595
23.5-25	PR 24	12500 (10 km/h)	19.50/2.5	1615	595
26.5-25	PR 24	14000 (10 km/h)	22.00/3.0	1750	675
26.5-25	PR 28	15500 (10 km/h)	22.00/3.0	1750	675
26.5-25	PR 32	17000 (10 km/h)	22.00/3.0	1750	675
29.5-25	PR 28	17500 (10 km/h)	25.00/3.5	1875	750
29.5-25	PR 32	19000 (10 km/h)	25.00/3.5	1875	750
14.00-24	PR 20	8500 (10 km/h)	10.00/2.0	1370	375
14.00-24	PR 24	9500 (10 km/h)	10.00/2.0	1370	375
14.00-24	PR 28	10000 (10 km/h)	10.00/2.0	1370	375
14.00-25	PR 24	9500 (10 km/h)	10.00/2.0	1370	375
14.00-25	PR 28	10000 (10 km/h)	10.00/2.0	1370	375
14.00-25	PR 32	10900 (10 km/h)	10.00/2.0	1370	375
16.00-24	PR 24	10600 (10 km/h)	11.25/2.0	1495	430
16.00-24	PR 28	11500 (10 km/h)	11.25/2.0	1495	430
16.00-25	PR 28	11500 (10 km/h)	11.25/2.0	1495	430
18.00-25	PR 28	13600 (10 km/h)	13.00/2.5	1615	500
18.00-25	PR 32	15000 (10 km/h)	13.00/2.5	1615	500
18.00-25	PR 36	16000 (10 km/h)	13.00/2.5	1615	500
18.00-25	PR 40	17000 (10 km/h)	13.00/2.5	1615	500
15.5/60-18	PR 18	3250 (10 km/h)	W12	1000	380
17.5/65-20	PR 18	3250 (10 km/h)	W14	1090	430

E3/L3(W3), E3/L3(W4), E4/L4(N2)

TRA: E3, L3, E4, L4

Three size tables: E3/L3(W3) (8.25-16 to 20.5/70-16), E3/L3(W4) (15/70-18 to 23.5-25) and E4/L4(N2) (23.5-25).

Sizes (9)

Size	TRA	Load (kg)	Rim	O.D. (mm)	S.W. (mm)
8.25-16	PR 12	/ (10 km/h)	6.50H	855	235
12.00-16	PR 16	/ (10 km/h)	6.50H	840	240
20.5/70-16	PR 16	/ (10 km/h)	8.50H	1075	410
15/70-18	PR 18	3115 (10 km/h)	9.00G	950	380
17.5-25	PR 16	7300 (10 km/h)	14.00/1.5	1350	445
23.5-25	PR 20	10900 (10 km/h)	19.50/2.5	1615	595
23.5-25	PR 24	12500 (10 km/h)	19.50/2.5	1615	595
23.5-25	PR 20	10900 (10 km/h)	19.50/2.5	1615	595
23.5-25	PR 24	12500 (10 km/h)	19.50/2.5	1615	595

R-4(1), R-4(2), F-3, R-3

TRA: R-4, F-3, R-3

Size tables for R-4(1) (10.5/80-18, 12.5/80-18), R-4(2) (16.9-24 to 18.4-26), F-3 (11L-15, 11L-16) and R-3 (23.1-26) patterns.

Sizes (11)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
10.5/80-18	PR 10	1935	370 kPa	9	925	274
12.5/80-18	PR 12	2625	370 kPa	9	985	308
16.9-24	PR 12	3250	260 kPa	W15L	1309	429
16.9-28	PR 12	3450	260 kPa	W15L	1410	429
17.5L-24	PR 12	3000	250 kPa	W15L	1241	445
19.5L-24	PR 12	3450	230 kPa	17	1314	495
21L-24	PR 12	3875	220 kPa	DW18	1378	533
18.4-26	PR 12	2985	230 kPa	DW16	1436	467
11L-15	PR 10	1060	360 kPa	8LB	783	279
11L-16	PR 12	1250	440 kPa	8LB	808	279
23.1-26	PR 14	5600	230 kPa	DW20	1500	595

TH801, TH802, TH803, TH804

Applications: backhoe loader

Size table for TH801, TH802, TH803 and TH804 patterns, 12.5/80-18 to 19.5L-24.

Sizes (4)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
12.5/80-18	PR 12	2625	370 kPa	9	985	308
16.9-24	PR 12	3250	260 kPa	W15L	1309	429
16.9-28	PR 12	3450	260 kPa	W15L	1410	429
19.5L-24	PR 12	3450	230 kPa	17	1314	495

E-3A

TRA: E-3
TT/TL: TL

Special construction design for high torque and heavy load service.

Sizes (4)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
21.00-25	PR 44	39580 (0 km/h_static)	11150/165	15.00/3.0	1750	572	42
21.00-25	PR 42	37370 (0 km/h_static)	1030/150	15.00/3.0	1750	572	42
18.00-25	PR 44	32290 (0 km/h_static)	1030/150	13.00/2.5	1636	510	41
18.00-25	PR 40	30600 (0 km/h_static)	1000/145	13.00/2.5	1636	510	41

E-4A

TRA: E-4
TT/TL: TL

Special construction design for high torque and heavy load service.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.00-33	PR 40		35600 (0 km/h_static)	1150/165	13.00/2.5	1860	509	69
18.00-25	PR 40		30600 (0 km/h_static)	1000/145	13.00/2.5	1684	528	65

M01V/M01VL; M02S

Construction: Radial
TRA: L-2, L-3, E-3
Stars: ** / ***
TT/TL: TL
Applications: grader

Increased tread volume for additional wear life and resistance to damage.

Sizes (32)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
15.5R25	L-2	176/160	7100/4500	6.5/5.25 bar	12.00/1.3	1277	394	25
15.5R25	E-2	176/160	7100/4500	6.5/5.25 bar	12.00/1.3	1277	394	25
17.5R25	L-3	182/167	8500/5450	6.5/5.25 bar	14.00/1.5	1348	445	28
17.5R25	E-3	182/167	8500/5450	6.5/5.25 bar	14.00/1.5	1348	445	28
20.5R25	L-3	193/177	11500/7300	6.5/5.25 bar	17.00/2.0	1490	521	31
20.5R25	E-3	193/177	11500/7300	6.5/5.25 bar	17.00/2.0	1490	521	31
23.5R25	L-3	201/185	14500/9200	6.5/5.25 bar	19.50/2.5	1617	597	34
23.5R25	E-3	201/185	14500/9200	6.5/5.25 bar	19.50/2.5	1617	597	34
26.5R25	L-3	204/193	18500/11500	6.5/5.25 bar	22.00/3.0	1750	673	37
26.5R25	E-3	204/193	18500/11500	6.5/5.25 bar	22.00/3.0	1750	673	37
29.5R25	L-3	193/177	16600/9300	6.5/5.25 bar	17.00/2.0	1490	521	31
29.5R25	E-3	193/177	16600/9300	6.5/5.25 bar	17.00/2.0	1490	521	31
20.5R25	L-3	190	11500	6.5 bar	17.00/2.0	1490	521	31
23.5R25	L-3	201	14500	6.5 bar	19.50/2.5	1617	597	34
26.5R25	L-3	209	18500	6.5 bar	22.00/3.0	1750	673	37
17.5R25	L-3	182	8500	6.5 bar	14.00/1.5	1348	445	28
16.00R25	E-3	177	7300	7.0 bar	11.25/2.0	1532	448	34
23.5R25	L-3	201/185	14500/9290	6.5/5.25 bar	19.50/2.5	1617	597	34
23.5R25	E-3	201/185	14500/9290	6.5/5.25 bar	19.50/2.5	1617	597	34
23.5R25	L-3	206/189	7000/10300	8.0/6.75 bar	19.50/2.5	1617	597	34
23.5R25	E-3	206/189	7000/10300	8.0/6.75 bar	19.50/2.5	1617	597	34
26.5R25	L-3	206/193	8500/11500	6.5/5.25 bar	22.00/3.0	1750	673	37
26.5R25	E-3	206/193	8500/11500	6.5/5.25 bar	22.00/3.0	1750	673	37
26.5R25	E-3	214	21200	8.0 bar	22.00/3.0	1750	673	37
29.5R25	L-3	216/200	22400/14000	6.5/5.25 bar	25.00/3.5	1873	750	43.5
29.5R25	E-3	216/200	22400/14000	6.5/5.25 bar	25.00/3.5	1873	750	43.5
29.5R25	L-3	221/204	25750/16000	8.0 bar	25.00/3.5	1975	750	43.5
29.5R25	E-3	221/204	25750/16000	8.0 bar	25.00/3.5	1975	750	43.5
29.5R29	L-3	218/202	23600/15000	6.5/5.25 bar	25.00/3.5	1975	750	43.5
29.5R29	E-3	218/202	23600/15000	6.5/5.25 bar	25.00/3.5	1975	750	43.5
29.5R29	L-3	223/206	27250/17000	8.0 bar	25.00/3.5	1975	750	43.5
29.5R29	E-3	223/206	27250/17000	8.0 bar	25.00/3.5	1975	750	43.5

M02V; MSDN

Construction: Radial
TRA: E-4, L-3, E-3
Stars: ** / ***
TT/TL: TL
Applications: grader

M02V: wide tread pattern design and low profile case; MSDN: excellent traction and maneuverability.

Sizes (21)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
16.00R25	E-4	177	7300	7.0 bar	11.25/2.0	1532	448	44
600/65R25	L-3	187/178	9750/7500	4.75 bar	19.50/2.5	1395	610	35.5
600/65R25	E-3	187/178	9750/7500	4.75 bar	19.50/2.5	1395	610	35.5
650/65R25	L-3	193/180	11500/8000	4.75 bar	19.50/2.5	1475	640	38.5
650/65R25	E-3	193/180	11500/8000	4.75 bar	19.50/2.5	1475	640	38.5
750/65R25	L-3	202/190	15000/10600	4.75 bar	24.00/3.0	1590	735	44.5
750/65R25	E-3	202/190	15000/10600	4.75 bar	24.00/3.0	1590	735	44.5
875/65R29	L-3	214/200	21200/15800	4.75 bar	28.00/3.5	1845	900	52.5
875/65R29	E-3	214/200	21200/15800	4.75 bar	28.00/3.5	1845	900	52.5
875/65R29	L-3	218/213	23600/20600	6.5 bar	28.00/3.5	1850	900	52.5
875/65R29	E-3	218/213	23600/20600	6.5 bar	28.00/3.5	1850	900	52.5
17.5R25	L-3	182/167	8500/5450	6.5/5.25 bar	14.00/1.5	1348	445	28
17.5R25	E-3	182/167	8500/5450	6.5/5.25 bar	14.00/1.5	1348	445	28
20.5R25	L-3	193/177	11500/7300	6.5/5.25 bar	17.00/2.0	1490	521	31
20.5R25	E-3	193/177	11500/7300	6.5/5.25 bar	17.00/2.0	1490	521	31
23.5R25	L-3	201/185	14500/9250	6.5/5.25 bar	19.50/2.5	1617	597	42.5
23.5R25	E-3	201/185	14500/9250	6.5/5.25 bar	19.50/2.5	1617	597	42.5
26.5R25	L-3	204/193	18500/11500	6.5/5.25 bar	22.00/3.0	1770	673	45
26.5R25	E-3	204/193	18500/11500	6.5/5.25 bar	22.00/3.0	1770	673	45
29.5R25	L-3	216/200	22400/14000	6.5/5.25 bar	25.00/3.5	1873	750	48
29.5R25	E-3	216/200	22400/14000	6.5/5.25 bar	25.00/3.5	1873	750	48

MSL+; MSL

Construction: Radial
TRA: L-5, L-4
Stars: ** / *** / ****
TT/TL: TL
Applications: scraper

MSL+ and MSL: excellent traction, superb side-cut resistance, better riding comfort; long tread life (L-5 and L-4 tread class respectively).

Sizes (14)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5R25	L-5	182	8500	6.5 bar	14.00/1.5	1399	445	68
17.5R25	L-5	193	11500	8.0 bar	14.00/1.5	1389	445	68
20.5R25	L-5	193	11500	6.5 bar	17.00/2.0	1548	521	78
23.5R25	L-5	201	14500	6.5 bar	19.50/2.5	1673	597	87
26.5R25	L-5	209	18500	6.5 bar	22.00/3.0	1798	673	96
26.5R25	L-5	213	20600	8.0 bar	22.00/3.5	1808	673	98
29.5R25	L-5	216	22400	6.5 bar	25.00/3.5	1921	750	104
29.5R29	L-5	218	23600	6.5 bar	25.00/3.5	2023	750	104
35/65R33	L-5	224	28000	6.5 bar	28.00/3.5	2065	889	97
35/65R33	L-5	225/229	29000/32500	8.0 bar	28.00/3.5	2065	889	97
23.5R25	L-4	201	14500	6.5 bar	19.50/2.5	1673	597	51
26.5R25	L-4	209	18500	6.5 bar	22.00/3.0	1798	673	60
29.5R25	L-4	216	22400	6.5 bar	25.00/3.5	1921	750	66.5
35/65R33	L-4	224	28000	6.5 bar	28.00/3.5	2065	889	62.5

MPVS/MPVS2; M03S

Construction: Radial
TRA: E-4, L-3, E-3
Stars: ** / ***
TT/TL: TL
Applications: articulated dump truck, rigid dump truck

MPVS/MPVS2: superior riding comfort, three compounds C1, R1, CS; MPVS2 only for 16.00R25. M03S: extra-deep grooves with strong traction.

Sizes (18)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
23.5R25	E-4	185	9250	5.25 bar	19.50/2.5	1673	597	48
26.5R25	E-4	193	11500	5.25 bar	22.00/3.0	1798	673	52
29.5R25	E-4	200	14000	5.25 bar	25.00/3.5	1921	750	57
29.5R29	E-4	202	15000	5.25 bar	25.00/3.5	2023	750	57
600/65R25	L-3	187/178	9750/7500	4.75 bar	19.50/2.5	1395	610	35.5
600/65R25	E-3	187/178	9750/7500	4.75 bar	19.50/2.5	1395	610	35.5
650/65R25	L-3	193/180	11500/8000	4.75 bar	19.50/2.5	1475	640	38.5
650/65R25	E-3	193/180	11500/8000	4.75 bar	19.50/2.5	1475	640	38.5
750/65R25	L-3	202/190	15000/10600	4.75 bar	24.00/3.0	1590	735	44.5
750/65R25	E-3	202/190	15000/10600	4.75 bar	24.00/3.0	1590	735	44.5
875/65R29	L-3	214/203	21200/15500	4.75 bar	28.00/3.5	1845	900	52.5
875/65R29	E-3	214/203	21200/15500	4.75 bar	28.00/3.5	1845	900	52.5
875/65R29	L-3	218/213	23800/20600	6.50 bar	28.00/3.5	1850	900	52.5
875/65R29	E-3	218/213	23800/20600	6.50 bar	28.00/3.5	1850	900	52.5
*16.00R25	E-4	177	7300	7.0 bar	11.25/2.0	1532	448	46
14.00R24	E-4	169	5800	8.0 bar	10.0	1418	383	38
14.00R25	E-4	169	6800	8.0 bar	10.00/1.5	1418	383	38
18.00R25	E-4	185	9250	7.0 bar	13.00/2.5	1673	498	47

M06S; MPOS

Construction: Radial
TRA: E-4
Stars: **
TT/TL: TL
Applications: rigid dump truck

M06S: extra-deep grooves with strong traction; MPOS: cool running innovative tread rubber compound with longer lasting casing and bead.

Sizes (6)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.00R25	E-4	185	9250	7.0 bar	13.00/2.5	1673	498	47
18.00R33	E-4	191	10900	7.0 bar	13.00/2.5	1877	498	49
21.00R35	E-4	200	14000	7.0 bar	15.00/3.0	1960	570	54
18.00R33	E-4	191	10900	7.0 bar	13.00/2.5	1877	498	54
21.00R35	E-4	201	14500	7.0 bar	15.00/3.0	2052	572	54
24.00R35	E-4	209	18500	7.0 bar	17.00/2.5	2160	653	58

LVHS; MS69

TRA: E-3
Stars: ***
TT/TL: TT/TL; TT
Applications: rigid dump truck, dump truck

LVHS: extra deep tread and big pattern blocks, high speed durability and heat resistance, mining truck tires on rough condition, small dumping truck application. MS69: extra deep tread and big pattern blocks for mining trucks on rough condition.

Sizes (5)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
13.00R25	E-3	163	7000	12.5	8.5	1295	338	28
14.00R24	E-3	169	10000	12.5	10.0/1.7	1355	370	28
14.00R25	E-3	169	10000	12.5	10.00/2.0; 10.0/2.0	1355	370	28
13.00R25	E-3	167	7000	12.5	8.5	1300	350	26
14.00R25	E-3	169	10000	12.5	10.00/2.0	1365	370	28

LVAS2; LVHS2

TRA: E-4
Stars: ***
TT/TL: TT
Applications: rigid dump truck, dump truck

LVAS2 and LVHS2: extra deep tread and big pattern blocks, high speed durability and heat resistance, mining truck tires on rough condition; LVHS2 also for small dumping truck application.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00R25	E-4	169	10000	12.5	10.00/2.0	1365	370	34
14.00R25	E-4	169	10000	12.5	10.00/2.0	1365	370	34

LVAS2; LVHS2

TRA: E-4
Stars: ***
TT/TL: TT
Applications: rigid dump truck, dump truck

LVAS2 and LVHS2 in 14.00R24: extra deep tread and big pattern blocks, high speed durability and heat resistance, mining truck tires on rough condition; LVHS2 also for small dumping truck application.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00R24	E-4	169	13000	12.5	10.00/2.0	1365	370	34
14.00R24	E-4	169	13000	12.5	10.00/2.0	1365	370	34

LVHS16; LVHS26

TRA: E-3, E-4
Stars: ****
TT/TL: TT
Applications: rigid dump truck, dump truck

LVHS16 and LVHS26: extra deep tread and big pattern blocks, high speed durability and heat resistance, mining truck tires on rough condition, small dumping truck application.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00R25	E-3	169	10000	12.5	10.00/2.0	1365	370	28
14.00R25	E-4	169	10000	12.5	10.00/2.0	1390	370	40

MSZ3

TT/TL: TT; TL
Applications: wheel loader

MSZ3 pattern size table with PR, TT/TL, depth, overall diameter, section width, standard rim, pressure (kPa) and load (kg); starred sizes can be filled.

Sizes (15)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14X18-20	32	8430	1030 kPa	15.00	1130	178	31.5
16X18-20	36	10020	1050 kPa	15.00	1130	419	47
42X13-20	32	9070	1030 kPa	9.00	1067	330	25
42X13-20	24	8430	1000 kPa	9.00	1067	330	25
38X16-15	32	7800	1000 kPa	11.50	1000	308	31
14.00-15	32	6305	1030 kPa	11.50	902	358	36
14.00-15	28	5820	1030 kPa	11.50	902	358	36
14.50-15	20	4740	900 kPa	11.50	902	358	26
10.00-15	24	5692	1030 kPa	7.50	917	284	28
10.00-15	16	3875	790 kPa	7.50	917	284	28
350/65-15	24	4615	1030 kPa	11.50	838	353	27
28X12.5-15	24	4150	1000 kPa	9.75	826	310	27
23X12.5-15	28	5855	1030 kPa	9.75	826	305	26
15.00-8	24	3470	800 kPa	13.00	627	368	24
7.50-10	16	1800	1030 kPa	5.00F	617	203	22

MSH4; MSE3; SUPERL5

TT/TL: TT; TL

Size table for three patterns, MSH4, MSE3 and SUPERL5, with PR, TT/TL, depth, overall diameter, section width, standard rim, pressure (kPa) and load (kg).

Sizes (10)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
8.00-20	16	4775	1200 kPa	6.5	890	299	39
8.25-20	16	5800	690 kPa	6.5	970	285	42
9.00-20	20	6875	1500 kPa	11	915	329	43
400/12.5-20	32	7220	1500 kPa	11	1020	320	48
600/12.5-20	52	33035	1500 kPa	19.5	620	620	45
20.00-20	36	12940	1600 kPa	15.00	1270	435	53
14.00-20	32	10825	1600 kPa	10.00	1245	375	50
14.00-24	28	9250	885 kPa	10.00	1245	375	50
12.00-20	28	8020	1600 kPa	8.5	1145	315	62
12.00-20	24	8180	1600 kPa	8.5	1135	315	57

L4S/L5S

TT/TL: TT; TL; TT/TL

Smooth tread L4S/L5S pattern size table with PR, TT/TL, depth, overall diameter, section width, standard rim, pressure (kPa) and load (kg).

Sizes (16)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.00-33	40	36600	1150 kPa	28.00-2.5	2043	500	54
18.00-33	40	36000	1150 kPa	28.00-2.5	2025	510	56
18.00-24	24	9520	850 kPa	9.00	1623	375	48.5
18.00-29	16	5600	790 kPa	7.5	1973	378	56
23.5-25	40	29000	635 kPa	25.00-3.5	2025	750	108
23.5-25	34	28000	635 kPa	25.00-3.5	2020	750	108
23.5-25	36	28250	635 kPa	22.00-3.0	2020	675	100
26.5-25	32	15000	730 kPa	28.00-2.5	2073	750	85
17.5-25	24	9500	635 kPa	14.00-1.5	1403	445	62
17.5-25	20	7300	575 kPa	14.00-1.5	1403	445	62/50.5/46.5
14.00-24	28	13500/16000	1000/925 kPa	10.00	1412/1450	380/355	72/68.5
12.00-24	24	10750	1000 kPa	8.5	1290	353	68.67
12.00-20	28	8620	1000 kPa	8.5	1173	340	67
12.00-20	20	6255	950 kPa	8.5	1145	315	52
10.00-20	18	7250	1000 kPa	7.5	1097	360	56
8.25-15	24	6070	1000 kPa	6.5	864	260	52

X'CAVATOR

TT/TL: TT
Applications: excavator

Self-cleaning open tread with mud breakers for traction, reinforced sidewall for stability, cut resistance, excellent grip and increased traction.

Sizes (6)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
8.25-20	16	1800	688 kPa	6.5	962	230	19
9.00-20	16	2430	719 kPa	7.00	1018	259	20
10.00-20	16	2900	719 kPa	7.50	1038	278	20
11.00-20	18	3350	719 kPa	8.00	1092	278	21
12.00-20	32	3874	813 kPa	8.50	1202	292	22
14.00-20	16	3350	725 kPa	8.00	1302	290	22

HF-3

TT/TL: TL
Applications: flotation

HF-3 GARDEN FLOTATION: wide tread, rounded shoulders and streamlined design for a smooth ride, good buoyancy and sandy pavement performance, uniform tread wear.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
29x12.5-15	8		950	320 kPa	10.00	750	320	13
26x12.00-12	8		1370	290 kPa	10.00	670	309	11.2

HF-3 TTM

TT/TL: TL
Applications: trencher

HF-3 TTM TRENCHER TRACTION MASTER: built for severe operational trencher machines, self-cleaning stepped tread lugs for traction, lugs designed for a smooth ride and increased stability.

Sizes (4)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
26x12.00-10	8	1550	380 kPa	10.00	670	309	17.8
26x12.00-12	8	1370	350 kPa	10.50	670	309	19.0
31x15.5-15	8	1980	310 kPa	13.00	802	402	19.0
29x12.5-15	8	1950	320 kPa	10.00	770	325	21.5

R4 MPT101

TRA: L-3B
TT/TL: TL
Applications: soft ground

R4 MPT101: open tread for flotation and traction on soft terrain, reinforced sidewall for stability and cut resistance, cut and wear resistant compound, heavy-duty service.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
405/70-20 (16.0/70-20)	L-3B		2600	310 kPa	13	16C4	407	24
405/70-20 (16.0/70-20)	L-3B		3000	350 kPa	13	16C4	407	24

E3/L3 LOADMAX

TRA: E-3, L-3
TT/TL: TT; TTTL

E3/L3 LOADMAX: larger horizontal pattern for driving performance, reinforced middle ribs against chipping, cut-resistant formula and pitch design for service life, high-strength carcass cords for sidewall strength, double reinforced bead for load performance.

Sizes (16)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
16/70-20	14	5160	450 kPa	13	1075	410	17
16/70-24	14	5600	450 kPa	13	1175	410	22
17.5-25	16	7380	475 kPa	14.00/1.5	1350	445	26
17.5-25	20	8250	575 kPa	14.00/1.5	1350	445	26
17.5-25	24	9250	700 kPa	14.00/1.5	1350	445	26
20.5-25	20	9580	450 kPa	17.00/2.0	1490	520	30
20.5-25	24	10300	525 kPa	17.00/2.0	1490	520	30
20.5-25	28	11500	625 kPa	17.00/2.0	1490	520	30
23.5-25	16	9580	300 kPa	19.50/2.5	1615	595	35
23.5-25	20	10700	375 kPa	19.50/2.5	1615	595	35
23.5-25	24	12500	475 kPa	19.50/2.5	1615	595	35
23.5-25	28	13600	550 kPa	19.50/3.5	1615	595	35
26.5-25	28	15500	475 kPa	22.00/3.0	1750	675	35
26.5-25	32	17000	550 kPa	22.00/3.0	1750	675	35
29.5-25	28	17500	475 kPa	25.00/3.5	1875	750	38
29.5-25	32	18700	525 kPa	25.00/3.5	1875	750	38

L-4S/L-5S

TRA: L-4S, L-5S
TT/TL: TT; TL

L-4S/L-5S smooth tread: for extreme harsh conditions such as shafts, tunnels and multi rock conditions; strengthened body and thickened tread for load capacity; high-strength specialized tread formula for cut, puncture and wear resistance.

Sizes (11)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
10.00-20	14	4750	750 kPa	7.5	1055	288	29
12.00-24	16	6150	675 kPa	8.5	1275	315	23
12.00-24	20	6900	825 kPa	8.5	1275	315	40
12.00-24	24	7500	975 kPa	8.5	1275	315	40
14.00-24	24	9500	850 kPa	10.00/2.0	1370	375	45
17.5-25	20	8250	575 kPa	14.00/1.5	1400	445	58
17.5-25	24	9350	750 kPa	14.00/1.5	1400	445	58
17.5-25	30	8250	575 kPa	14.00/1.5	1400	445	63
17.5-25	34	9290	750 kPa	14.00/1.5	1400	445	63
18.00-25	32	15000	750 kPa	13.00/2.5	1675	595	78
18.00-25	40	17000	850 kPa	13.00/2.5	1675	595	78

MS-SN

TT/TL: TL
Applications: ice and snow

MS-SN snow tyre: special compound to increase friction on ice and snow roads; pattern design clears water, snow, mud and ice to reduce slipping.

Sizes (7)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
10-16.5	10	1389	410 kPa	8.25	773	254	30
12-16.5	12	2385	550 kPa	9.75	831	307	30
14-17.5	14	2875	550 kPa	10.5	921	348	30
16-9.24	14	2620	300 kPa	W15L	1335	439	24
16-9.28	14	4849	300 kPa	W15L	1435	439	24
18-20.24	12	2145	210 kPa	DW16	1340	495	28
21-8.24	16	2795	250 kPa	DW18	1490	576	28

MS-ML

TT/TL: TT
Applications: muddy ground

MS-ML: deep directional pattern for traction and self-cleaning, wide tread for flotation and driving on muddy roads, high strength and hardness tread compound for anti-cutting, anti-puncture and wear resistance.

Sizes (3)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
15-20	18	3700	420 kPa	11.00Y	1210	354	30
1200×520-533	18	5930	620 kPa	440-533	1200	533	30
14.00-20	20	5000\4375	730/790 kPa	10	1265	375	38

Underground mining

MA05

Construction: All steel radial
TRA: L5
Stars: **
TT/TL: TL
Applications: wheel loader, grader, scraper, underground loader or truck

All steel radial construction; high-tech casing reduces heat build up; extra deep L5 rock tread and reinforced shoulders and sidewalls prevent damage in severe operating conditions.

Sizes (3)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5R25	L5	182A2	8500	6.5	14.00/1.5	1397	483	65
26.5R25	L5	209A2	18500	6.5	22.00/3.0	1803	686	91
29.5R25	L5	216A2	22400	6.5	25.00/3.5	1905	787	100

MA07+

Construction: All steel radial
TRA: L5
Stars: ***
TT/TL: TL
Applications: wheel loader, underground loader or truck

All steel radial construction; high-tech casing reduces heat build up; L5 tread pattern protects against tears, wear and cuts while providing stability, comfort and traction.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
35/65R33	L5	229A2	32500	8.0	28.0/3.5	2080	870	97

MA08

Construction: All steel radial
TRA: L4, L5
Stars: **
TT/TL: TL
Applications: wheel loader, grader, scraper, underground loader or truck

All steel radial construction; high-tech casing reduces heat build up; massive tread blocks and aggressive L4/L5 open tread design provide outstanding grip and traction.

Sizes (8)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5R25	L5	182A2	8500	6.5	14.00/1.5	1400	440	65
20.5R25	L5	195A2	11500	6.5	17.00/2.0	1548	521	72
23.5R25	L5	201A2	14500	6.5	19.50/2.5	1662	592	78
26.5R25	L5	209A2	18500	6.5	22.00/3.0	1800	665	87
29.5R25	L5	216A2	22400	6.5	25.00/3.5	1900	720	95
29.5R29	L5	218A2	23600	6.5	25.00/3.5	1960	750	95
35/65R33	L4	224A2	28000	6.5	28.00/3.5	2075	880	63
35/65R33	L5	224A2	28000	6.5	28.00/3.5	2075	880	97

MA10

Construction: All steel radial
TRA: L5
Stars: **
TT/TL: TL
Applications: wheel loader, grader, dump truck, underground loader or truck

All steel radial construction; high-tech casing reduces heat build up; extra deep L5 tread pattern for excellent traction in the most severe circumstances.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
20.5R25	L5	193A2	11500	6.5	17.00/2.0	1549	555	72
23.5R25	L5	202A2	14500	6.5	19.50/2.5	1636	609	78

MA10+

Construction: All steel radial
TRA: L5
Stars: **
TT/TL: TL
Applications: wheel loader, grader, dump truck, underground loader or truck

All steel radial construction; high-tech casing reduces heat build up; super deep open tread pattern designed for wheel loaders, dozers and grader requiring maximum traction.

Sizes (6)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
15.5R25	L5	176A2	7100	6.5	12.00/1.5	1335	395	60
17.5R25	L5	182A2	8500	6.5	14.00/1.5	1460	440	68
20.5R25	L5	193A2	11500	6.5	17.00/2.0	1590	520	70
23.5R25	L5	201A2	14500	6.5	19.50/2.5	1676	595	76
26.5R25	L5	209A2	18500	6.5	22.00/3.0	1800	675	86
29.5R25	L5	216A2	22400	6.5	25.00/3.5	1930	750	96

MU25

TRA: E4, L4
Stars: *** / ****
TT/TL: TL
Applications: underground loader or truck, wheel loader

Aggressive E4/L4 open tread pattern gives outstanding grip and traction; even contact area minimises vibration for operator comfort; directional block design and square shoulders provide outstanding durability.

Sizes (4)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
29.5R29	L4	225A2	29000	8.0	25.00/3.5	2000	760	65
29.5R29	E4	219A8	24300	8.0	25.00/3.5	2000	760	65
35/65R33	L4	229A2	32500	8.0	28.00/3.5	2062	900	62
35/65R33	E4	225A8	29000	8.0	28.00/3.5	2062	900	62

MU30

Construction: Radial
TRA: E4, L4
Stars: *** / ****
TT/TL: TL
Applications: underground loader or truck, wheel loader

Reinforced radial casing gives outstanding damage resistance and load capacity; reinforced sidewalls increase shock and abrasion resistance; massive lugs and cut-resistant centre give tread robustness and service life.

Sizes (4)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
26.5R25	L4	214A2	21200	8.0	22.00/3.0	1730	660	56
26.5R25	E4	210B	19000	8.0	22.00/3.0	1730	660	56
29.5R25	L4	221A2	25750	8.0	25.00/3.5	1865	765	59
29.5R25	E4	210A8	23000	8.0	25.00/3.5	1865	765	59

MA05S

Construction: All steel radial
TRA: L5S
Stars: ** / ***
TT/TL: TL
Applications: underground loader or truck

All steel radial construction; high-tech casing reduces heat build up; extra-deep L5S smooth design provides best resistance to wear and cutting and lowers operating costs.

Sizes (6)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5R25	L5S	182A2	8500	6.5	14.00/1.5	1400	445	66
18.00R25	L5S	200A2	17900	8.25	13.00/2.5	1675	500	82
26.5R25	L5S	209A2	18500	6.5	22.00/3.0	1800	675	94
29.5R25	L5S	216A2	22400	6.5	25.00/3.5	1921	732	100
29.5R29	L5S	218A2	23000	6.5	25.00/3.5	2015	732	100
35/65R33	L5S	224A2	28000	6.5	28.00/3.5	2060	895	97

MB05S

Construction: Bias (cross-ply)
TRA: L5S
TT/TL: TL
Applications: underground loader or truck

All cross ply construction; high-tech casing reduces heat build up; special tread compound and smooth deep tread design provide excellent resistance and improve tyre service life.

Sizes (7)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
10.00-20	L5S	164A3	4695	6.9	7.50	1055	278	40
11.00-20	L5S	178A3	7500	11.0	8.50	1173	313	43
12.00-24	LSS	181A3	8250	11.5	8.50	1273	313	47
14.00-24	L5S	188A3	10000	9.5	10.00	1420	375	44
17.5-25	L5S	193A3	9250	6.9	14.00	1600	445	45
18.00-25	L5S	204A3	17000	9.5	13.00	1675	500	79
26.5-25	L5S	209A3	18500	6.25	22.00	1800	675	88

LMS+; LMGS+

Construction: Radial
TRA: L-5S
Stars: ** / ***
TT/TL: TL, TT/TL
Applications: underground loader or truck, scraper

Extremely smooth deep tread and robust shoulders; sidewall protection against shock ruptures.

Sizes (12)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
12.00R24	L-5S	175	6900	8.0 bar	8.50	1255	315	55
14.00R24	L-5S	186	9500	8.0 bar	10.00W	1368	369	60
17.5R25	L-5S	182	8500	6.5 bar	14.00/1.5	1399	445	65
20.5R25	L-5S	193	11500	6.5 bar	17.00/2.0	1548	521	72
20.5R25	L-5S	200	14000	8.0 bar	17.00/2.0	1548	521	72
23.5R25	L-5S	201	14500	6.5 bar	19.50/2.5	1673	597	83
26.5R25	L-5S	209	18500	6.5 bar	22.00/3.0	1808	673	90
29.5R25	L-5S	216	22400	6.5 bar	25.00/3.5	1921	750	100
29.5R29	L-5S	218	23600	6.5 bar	25.00/3.5	2023	750	100
18.00R25	L-5S	204	16000	8.25 bar	13.00/2.5	1655	515	80
35/65R33	L-5S	224	28000	6.5 bar	28.00/3.5	2065	889	97
12.00R24	L-5S	175	6900	8.0 bar	8.5	1270	324	55

G2; L5

Construction: Bias (cross-ply)
TRA: L-3, G-2, E-3, G-1, L-5
TT/TL: TT
Applications: scraper

G2 pattern has good traction stability and self-cleaning for hard road and mining work; L5 ultra-deep block pattern for loaders and scrapers in mining, forest and underground operations.

Sizes (9)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5-25	L-3	7500/8250	4.75/3.5 bar	14.00/1.5	1390	445	28
17.5-25	G-2	7500/8250	4.75/3.5 bar	14.00/1.5	1390	445	28
20.5-25	E-3	8250/5450	4.5/3.25 bar	17.00/2.0	1490	520	28
20.5-25	G-1	8250/5450	4.5/3.25 bar	17.00/2.0	1490	520	28
23.5-25	L-3	9500/6150	3.5/2.5 bar	19.50/2.5	1615	595	33.5
23.5-25	G-2	9500/6150	3.5/2.5 bar	19.50/2.5	1615	595	33.5
26.5-25	E-3	15500/10300	4.75/3.5 bar	22.00/3.0	1750	675	39
26.5-25	L-3	15500/10300	4.75/3.5 bar	22.00/3.0	1750	675	39
23.5-25	L-5	12630	4.75 bar	19.50/2.5	1915	606	70.5

Port, terminal and industrial

MR400

Construction: Steel belted radial
TRA: IND
TT/TL: TL
Applications: backhoe loader, excavator, dozer

Steel belted construction; high-tech casing reduces heat build up; deep tread and traction pattern improves performance with excellent self-cleaning properties.

Sizes (8)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
460/70 (17.5)R24	IND	159B	4375	4.0	15.00	1254	455	36
530/70 (19.5)R24	IND	164B	5000	4.0	16.00	1300	565	38
540/70 (21LR)24	IND	161B	4625	5.2	18.00	1346	593	40
480/80 (18)R24	IND	158B	4250	5.0	15.00	1170	484	33
400 (15.5)R24	IND	155B	4000	4.0	15.00	1250	484	35
440/80 (16.9)R24	IND	161B	4625	4.0	14.00	1334	443	37
440/80 (16.9)R28	IND	159B	4000	5.2	14.00	1415	443	38
480/80 (18.4)R28	IND	169B	4500	5.2	16.00	1493	479	38

MB01

Construction: Bias (cross-ply)
TRA: IND-3, IND-4
TT/TL: TL
Applications: straddle carrier, port machinery, reach stacker, forklift, container handler

High-tech casing reduces heat build up; all cross-ply construction with improved protector plies; non-directional IND-3/IND-4 tread design for improved traction.

Sizes (4)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
16.00-25	IND-3	22900 (static)	10.0	11.25/2.0	1415	440	32
21.00-25	IND-3	35400 (static)	10.0	15.00/3.0	1799	585	58
18.00-35	IND-4	37300 (static)	10.0	13.00/2.5	1877	498	65
21.00-35	IND-3	45700 (static)	10.0	15.00/3.0	2045	570	58

MB01S

Construction: Bias (cross-ply)
TRA: IND-4
TT/TL: TL
Applications: straddle carrier, reach stacker

High-tech casing reduces heat build up; all cross-ply construction with improved protector plies; smooth tread with non-directional IND-3/IND-4 tread design.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.00-25	IND-4		51500 (static)	10.0	13.00/2.5	1678	500	65

M-STACKER

Construction: Bias (cross-ply)
TRA: IND-4
TT/TL: TL
Applications: straddle carrier, port machinery, container handler, reach stacker

All cross-ply construction; high-tech casing reduces heat build up; deep, wide tread grooves support easier turning by reducing stress in tread blocks.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.00-25	IND-4		51500 (static_loaded_wheel)		13.00/2.5	1660	480	50

M-STACKER+

Construction: Bias (cross-ply)
TRA: IND-4
TT/TL: TL
Applications: reach stacker

All cross-ply construction; high-tech casing reduces heat build up; deep, wide tread grooves support easier turning by reducing stress in tread blocks.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.00-25	IND-4		51600 (static_wheel)		13.00/2.5	1650	483	70

MB02

Construction: Bias (cross-ply)
TRA: IND-5, IND-4
TT/TL: TL
Applications: dump truck, wheeled excavator, container handler, reach stacker

All cross-ply construction with improved protector plies; high-tech casing reduces heat build up; non-directional IND-5/IND-4 tread design.

Sizes (6)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
11.00-20	IND-5	10350 (static)	8.5	8.0	1085	295	22
12.00-24	IND-4	12500 (static)	10.0	8.5	1245	315	35
14.00-24	IND-4	18000 (static)	10.0	10.0	1370	375	50
18.00-25	IND-5	29200 (static)	11.4	13.00/2.5	1635	510	45
18.00-25	IND-4	29200 (static)	10.0	13.00/2.5	1675	515	55
18.00-33	IND-4	38200 (static)	10.0	13.00/2.5	1875	560	60

MB300

Construction: Bias (cross-ply)
TRA: IND-5
TT/TL: TT
Applications: terminal tractor, container handler, forklift, reach stacker

All cross-ply construction with improved protector plies; high-tech casing reduces heat build up; deep non-directional tread design.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00-24	IND-5		10000 (static)	9.25	10.00	1370	275	26

MB300+

Construction: Bias (cross-ply)
TRA: IND-5
TT/TL: TT/TL
Applications: dump truck, container handler, forklift, reach stacker

All cross-ply construction with improved protector plies; high-tech casing reduces heat; deep nondirectional tread design.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00-24	IND-5		12000 (static)	10.0	10.00	1370	375	30

MB800

Construction: Bias (cross-ply)
TRA: IND
TT/TL: TT
Applications: forklift, terminal tractor, telehandler, port machinery, industrial vehicle

All cross-ply construction with improved protector plies; high-tech casing reduces heat build up; self-cleaning and non-directional tread pattern.

Sizes (11)

Size	TRA	Load (kg)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
5.60-8	IND	1150 (drive_wheel_25 km/h)	3.50	630	157	11
6.00-9	IND	1505 (drive_wheel_25 km/h)	4.00	540	140	12
6.50-10	IND	1995 (drive_wheel_25 km/h)	5.00	578	150	13
7.00-12	IND	2590 (drive_wheel_25 km/h)	5.00	636	170	14
8.25-15	IND	3575 (drive_wheel_25 km/h)	6.50	798	230	18
28x9-15	IND	3920 (drive_wheel_25 km/h)	7.00	798	230	18
250-15	IND	4130 (drive_wheel_25 km/h)	7.50	735	250	18
300-15	IND	5940 (drive_wheel_25 km/h)	8.00	840	390	20
10.00-20	IND	6920 (drive_wheel_25 km/h)	7.50	1074	277	22
11.00-20	IND	7730 (drive_wheel_25 km/h)	8.50	1145	315	24
12.00-20	IND	8500 (drive_wheel_25 km/h)	8.50	1145	350	26

MR800+

Construction: All steel radial
TRA: IND-4
Stars: ** / ***
TT/TL: TL/TT
Applications: terminal tractor, articulated dump truck, excavator, port machinery, skid steer loader, wheeled excavator, container handler

All steel radial construction with improved protector plies; special tread compound to run cool, fight rapid wear and deliver remarkable stability.

Sizes (9)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
9.00R20	IND-4	160A5	4500	10.0	7.00	1020	270	35
10.00R20	IND-4	164A5	5000	10.0	7.00	1054	280	35
11.00R20	IND-4	170A5	6000	10.0	8.00	1090	294	39
12.00R20	IND-4	174A5	7100	10.0	8.50	1130	325	40
12.00R24	IND-4	178A5	7900	10.0	8.50	1222	325	40
14.00R24	IND-4	193A5	11200	10.0	10.0	1428	386	65
16.00R25	IND-4	200A5	14000	10.0	11.25/2.0	1530	420	71
18.00R25	IND-4	207A5	17500	10.0	13.00	1644	512	65
18.00R33	IND-4	216A5	24300	10.0	13.00	1838	475	70

M-TERMINAL

Construction: All steel radial
TRA: IND-5
TT/TL: TL
Applications: terminal tractor, port machinery

All steel radial construction; deep tread profile and industrial casing give high resistance to damage and punctures.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
280/75R22.5	IND-3	168A8	5600	10.0	7.50/8.25	968	275	32
310/80R22.5	IND-3	175A8	6900	10.0	8.25/9.00	1078	300	32

M-TERMINAL+

Construction: All steel radial
TRA: IND-3
TT/TL: TL
Applications: terminal tractor, port machinery

All steel radial construction; deep tread profile and industrial casing give high resistance to damage and punctures.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
310/80R22.5	IND-3	168A8	6900	10.0	9.00	1080	330	50

M-STRADDLE

Construction: All steel radial
TRA: IND-4
Stars: **
TT/TL: TL
Applications: straddle carrier

All steel radial construction; deep and ribbed tread pattern guarantees excellent resistance to damage and impacts.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
16.00R25	IND-4	202A7	15000	10.0	11.25/2.0	1550	450	50

M-STRADDLE+

Construction: All steel radial
TRA: IND-3, IND-4
Stars: **
TT/TL: TL
Applications: straddle carrier

All steel radial construction; deep and ribbed tread pattern guarantees excellent resistance to damage and impacts.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
36.00R25	IND-4	202A7	15000	10.0	11.25/2.0	1550	450	48
48/95R25	IND-4	208A5	17000	10.0	13.00/2.5	1535	450	59

MA600

Applications: wheel loader, excavator, reach stacker, straddle carrier

Extremely stable at slow speed and stationary high load applications; high manoeuvrability while minimising risk of tread cracks; improved abrasion resistance.

Sizes (5)

Size	Load (kg)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
16.00-25	11800 (10 km/h_drive)	11.25/2.0	1456	433	105
18.00-25	22120 (10 km/h_drive)	13.00/2.5	1615	480	114
20.5-25	23000 (10 km/h_drive)	17.00/2.0	1500	544	125
23.5-25	30960 (10 km/h_drive)	19.50/2.5	1680	595	150
26.5-25	39300 (10 km/h_drive)	22.00/3.0	1796	657	155

MA608

Applications: terminal tractor, port machinery, wheel loader, forklift, reach stacker, container handler

Extremely stable, puncture resistant and maintenance-free with high loading capacity for forklift trucks and other industrial applications; large profile blocks for traction on a wide range of surfaces.

Sizes (7)

Size	Load (kg)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
10.00-20	6845 (5 km/h_drive)	7.0	2022	250	65
10.00-20	7075 (5 km/h_drive)	7.5	2022	250	65
12.00-24	8640 (5 km/h_drive)	8.0	2081	325	74
12.00-24	8920 (5 km/h_drive)	8.5	2081	325	74
12.00-24	9115 (5 km/h_drive)	8.5	2300	393	92
14.00-24	13165 (5 km/h_drive)	10.0	2546	542	82
14.00-25	13210 (5 km/h_drive)	11.25	2555	581	82

MA608

Construction: Solid
Applications: forklift

Solid tyres specifically designed for forklifts, offering stability, puncture resistance and long-lasting performance with high loading capacity.

Sizes (35)

Size	Load (kg)	Rim	O.D. (mm)	S.W. (mm)
15x4 1/2-8	1105 (6 km/h)	3.00	375	110
16x6-8	1495 (6 km/h)	4.33	405	145
5.00-8	1495 (6 km/h)	3.00	445	120
18x7-8	2540 (6 km/h)	4.33	445	155
6.00-9	2080 (6 km/h)	4.00	520	145
21x8-9	3120 (6 km/h)	6.00	315	180
140/55-9	1300 (6 km/h)	4.00	375	130
17 3/4x6 1/2-10	1950 (6 km/h)	5.00	450	165
180/60-10	1950 (6 km/h)	5.00	450	165
200/50-10	2470 (6 km/h)	6.50	450	195
6.50-10	2600 (6 km/h)	5.00	560	155
23x9-10	3900 (6 km/h)	6.50	565	200
7.00-12	3250 (6 km/h)	8.00	640	165
23x10-12	3900 (6 km/h)	8.00	570	235
27x10-12	4550 (6 km/h)	8.00	665	235
5.50-15	2470 (6 km/h)	4.50	650	145
6.00-15	2470 (6 km/h)	4.50	685	145
7.00-15	3900 (6 km/h)	5.50/6.00	720	175
7.50-15	4420 (6 km/h)	5.50/6.00	740	190
8.15-15	3900 (6 km/h)	7.00	680	210
250-15	4940 (6 km/h)	7.00/7.50	710	225
22 1/4x7 1/2-15	3120 (6 km/h)	5.50	565	190
8.25-15	5460 (6 km/h)	6.50	800	200
300-15	6500 (6 km/h)	8.00	800	250
28x12.5-15	6240 (6 km/h)	9.75	700	290
355/65-15	8060 (6 km/h)	9.75	810	290
7.50-16	4420 (6 km/h)	6.00	770	185
8.25-20	6500 (6 km/h)	6.00/6.50	980	220
9.00-20	6500 (6 km/h)	7.00	980	220
10.00-20	7800 (6 km/h)	7.00/7.50/8.00	1010	250
11.00-20	7800 (6 km/h)	7.00/7.50/8.00	1040	250
12.00-20	8450 (6 km/h)	7.00/7.50/8.00	1090	265
12.00-24	10140 (6 km/h)	8.00/8.50	1200	285
14.00-24	13650 (6 km/h)	10.00	1330	335
14.00-25	13650 (6 km/h)	10.00	1330	335

MA608 TWIN WHEEL

Construction: Solid
Applications: wheeled excavator

Solid twin-wheel tyre for mobile excavators with massive non-directional tread; 3-stage technology of rubber tread, cushion and FRRC base reinforced by steel cords.

Sizes (5)

Size	Load (kg)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
20.00-20	14520 (6 km/h_drive)	7.5	1662	557	65
12.00-20	17180 (6 km/h_drive)	8.0	1681	595	74
13.00-24	18190 (6 km/h_drive)	8.5	1998	640	91
14.00-24	24330 (6 km/h_drive)	10.0	1846	765	83
14.00-25	24430 (6 km/h_drive)	11.25	1333	762	83

MA608S

Construction: Solid
Applications: terminal tractor

Solid slick profile with maximum contact area for smooth surfaces such as ports, shipyards and airports; abrasion-resistant tread compound for reliability and long service life.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
10.00-20			5185 (6 km/h)		7.5	1100	240
11.00-20			6430 (6 km/h)		8.0	1262	209

TH201, TH202, TH203

TT/TL: TT
Applications: forklift

Size table for TH201, TH202 and TH203 industrial patterns, 5.00-8TT to 12.00-20TT, with load capacity at 25 km/h drive.

Sizes (17)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
5.00-8TT	PR 10	1150	1000 kPa	3.500	470	137
6.00-9TT	PR 10	1505	860 kPa	4.00E	540	160
6.50-10TT	PR 10	1655	790 kPa	5.00F	590	175
7.00-12TT	PR 14	2590	1000 kPa	5.00S	676	190
7.00-15TT	PR 14	3140	1000 kPa	5.5	750	200
7.50-15TT	PR 14	3375	925 kPa	6.0	780	215
8.25-15TT	PR 14	3775	830 kPa	6.5	840	235
18*7-8TT	PR 16	1640	1000 kPa	4.33R	465	173
21*8-9TT	PR 14	2040	1000 kPa	6.00E	535	200
23*10-12TT	PR 14	2810	1030 kPa	8.00G	597	254
23*9-10TT	PR 16	2810	1030 kPa	6.50F	595	225
250-15TT	PR 16	3865	930 kPa	7.5	735	250
27*10-12TT	PR 14	3285	860 kPa	8.00G	690	255
28*9-15TT (8.15-15)	PR 14	3050	970 kPa	7.0	706	220
300-15TT	PR 20	5940	930 kPa	8.0	840	300
10.00-20TT	PR 16	6030	790 kPa	7.5	1055	278
12.00-20TT	PR 20	7400	1000 kPa	8.5	1125	315

TH200

Applications: forklift

TH200 pattern size table, 4.00-8 to 300-15, with load capacity (kg) drive/steer at 10, 16 and 25 km/h for balance forklifts and other forklifts.

Sizes (28)

Size	Load (kg)	Rim	O.D. (mm)	S.W. (mm)
4.00-8	1090/840 (10 km/h_drive_steer)	3.00	423	121
5.00-8	1255/965 (10 km/h_drive_steer)	3.00	469	146
200/50-10	2910/2240 (10 km/h_drive_steer)	6.50	460	221
6.00-9	1975/1520 (10 km/h_drive_steer)	4.00	545	160
6.50-10	2715/2090 (10 km/h_drive_steer)	5.00	597	178
7.00-9	2870/2055 (10 km/h_drive_steer)	5.00	578	186
7.00-12	3105/2380 (10 km/h_drive_steer)	5.00	683	192
7.00-15	3700/2845 (10 km/h_drive_steer)	5.50	750	204
7.50-15	3805/2925 (10 km/h_drive_steer)	5.50	774	215
7.50-16	4035/3105 (10 km/h_drive_steer)	5.50	820	220
28*9-15TT (8.15-15)	4060/3125 (10 km/h_drive_steer)	7.0	706	225
8.25-12	3425/2635 (10 km/h_drive_steer)	5.00	735	236
8.25-15	4305/3310 (10 km/h_drive_steer)	5.50	847	236
8.25-20	5165/4305 (10 km/h_drive_steer)	6.50	992	236
9.00-16	5290/4070 (10 km/h_drive_steer)	6.50	884	259
9.00-20	6365/5305 (10 km/h_drive_steer)	7.0	1038	259
10.00-20	7070/5985 (10 km/h_drive_steer)	7.5	1073	278
11.00-20	7470/6225 (10 km/h_drive_steer)	7.5	1095	300
12.00-20	8640/7200 (10 km/h_drive_steer)	8.0	1180	310
21*8-9	2890/2225 (10 km/h_drive_steer)	6.00	535	207
15*4 1/2-8	1005/775 (10 km/h_drive_steer)	3.00	380	114
16*6-8	1545/1190 (10 km/h_drive_steer)	4.33	418	162
18*7-8	2430/1870 (10 km/h_drive_steer)	4.33	457	170
23*9-10	3730/2870 (10 km/h_drive_steer)	6.50	595	225
23*10-12	4450/3425 (10 km/h_drive_steer)	8.00	595	281
27*10-12	4595/3535 (10 km/h_drive_steer)	8.00	683	281
250-15	5595/4305 (10 km/h_drive_steer)	7.5	735	250
300-15	6895/5305 (10 km/h_drive_steer)	8.0	838	300

E-4/IND-4

TRA: E-4, IND-4
TT/TL: TL, TT/TL, TT
Applications: port machinery

Strong carcass provides superior load capacity.

Sizes (10)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.00-25	PR 40	30800 (static)	1000	13.00/2.5	1673	526	69
18.00-25	PR 36	27450 (static)	1100	11.25/2.0	1548	432	62
16.00-25	PR 32	22100 (static)	1000	11.25/2.0	1548	432	62
16.00-25	PR 28	20040 (static)	1300	11.25/2.0	1548	432	62
14.00-25	PR 28	19600 (static)	1100	10.00/1.5	1417	386	57
14.00-24	PR 32	19653 (static)	1600	10.00	1417	386	57
14.00-24	PR 28	18000 (static)	1000	10.00	1417	386	57
12.00-24	PR 24	13900 (static)	1400	8.5	1300	333	54
12.00-20	PR 24	14260 (static)	1000	8.5	1173	340	45
10.00-20	PR 18	9430 (static)	1000	7.5	1087	300	49

L-4S/L-5S

TRA: L-4S, L-5S
TT/TL: TL, TT/TL, TT
Applications: port machinery

Specially designed strong carcass with wide running surface and deep tread for longer tire life.

Sizes (9)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.00-25	PR 40	30860 (static)	1000	13.00/2.5	1673	526	58
21.00-25	PR 40	36385 (static)	1400	15.00/3.0	1798	617	97
18.00-25	PR 40	30860 (static)	1400	13.00/2.5	1673	538	85
14.00-25	PR 28	18000 (static)	1400	10.00	1417	386	77
14.00-24	PR 28	18000 (static)	1400	10.00	1417	386	77
12.00-24	PR 24	13900 (static)	1400	8.5	1300	333	55
12.00-20	PR 28	25620 (static)	1500	8.5	1173	300	67
10.00-20	PR 18	9430 (static)	1400	7.5	1087	300	58
8.25-15	PR 24	6070 (static)	1000	6.5	864	260	52

M04S; M04S2; MSD

Construction: Radial
TRA: E-4, IND-4
Stars: ** / ***
TT/TL: TL
Applications: rigid dump truck, port machinery

M04S reduces wheel spin in bad conditions; M04S2 recommended for rigid dump trucks; MSD offers longer tire life and stronger durability.

Sizes (7)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.00R33	E-4	191	10900	7.8 bar	13.00/2.5	1877	498	54
18.00R35	E-4	201	14500	7.8 bar	15.00/3.0	2068	572	61
24.00R35	E-4	200	16500	7.8 bar	17.00/3.5	2175	653	68
18.00R33	E-4	191	10900	7.8 bar	13.00/2.5	1877	498	54
18.00R35	E-4	201	14500	7.8 bar	15.00/3.0	2068	572	61
24.00R35	E-4	200	16500	7.8 bar	17.00/3.5	2175	653	68
16.00G25	IND-4	200	14000	10 bar	11.25/2.0	1613	426	53

D08S; D07S

Construction: Radial
TRA: IND-4
Stars: ** / ***
TT/TL: TL
Applications: forklift, terminal tractor, industrial vehicle, reach stacker

D08S: massive tread and heat-resistant low abrasion rubber; D07S: rugged radial tyre for forklift trucks, terminal tractors and other heavy-duty industrial equipment.

Sizes (6)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
12.00R24	IND-4	175	7300	10 bar	8.5	1242	343	41.5
16.00R25	IND-4	200	14000	10 bar	11.25/2.0	1530	438	72.5
18.00R26	IND-4	214	21200	10 bar	13.00/2.5	1680	519	80
18.00R33	IND-4	219	24000	10 bar	13.00/2.5	1800	519	72
14.00R24	IND-4	196	12500	10 bar	13.00W	1325	300	64.5
18.00R25	IND-4	214	21200	10 bar	13.00/2.5	1690	519	63

M05V; C-7

Construction: Bias (cross-ply)
TRA: C-7
Stars: ** / ***
TT/TL: TL, TT
Applications: port machinery, compactor

M05V: heat resistance compound and high speed durability; C-7: special pattern for road roller.

Sizes (7)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00R24 (335/95R24)	E-2	170	6000	10 bar	10.00W	1356	382	23
14.00R25 (385/95R25)	E-2	170	6000	10 bar	10.00/1.5	1356	382	23
16.00R25 (445/95R25)	E-2	174/177	6700/7300	10 bar	11.25/2.0	1493	432	28
17.5R25 (445/80R25)	E-2	170	6000	8 bar	14.00/1.5	1348	445	28
20.5R25 (525/80R25)	E-2	179	7750	8 bar	17.00/2.0	1490	521	31
18.00R25 (505/95R25)	E-2	186	9500	9.0 bar	13.00/2.5	1615	498	28
23.1-26	C-7		5150	2 bar	DW20	1500	595	17

G-3; MS62

TRA: E-3(G-3), E-4
TT/TL: TT
Applications: port machinery, rigid dump truck

G-3: high strength tyre carcass, wear resistance tread design with low heat and good heat dissipation, cut and abrasion resistance for heavy-duty mine transport vehicles. MS62: extra deep tread and big pattern blocks for mining trucks on rough condition.

Sizes (5)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
13.00-25NHS	E-3(G-3)		9250/4875	10.5/7	10.00/1.5	1300	350	29.5
14.00-24NHS	E-3(G-3)		10000/5000	9.2/6.5	10.0	1370	375	31
14.00-25NHS	E-3(G-3)		10000/5000	9.2/6.5	10.00/1.5	1370	375	31
13.00R25	E-4	163	7000	12.5	8.5	1300	338	31
14.00R25	E-4	169	10000	12.5	10.00/2.0	1350	370	40

F3 MR

TT/TL: TL

F3 MR MULTI-RIB: low section height for handling and stability, industry standard for towhose front tires, large footprint and wide tread for load distribution, deep grooves for directional control, durable nylon casing.

Sizes (6)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
11L-15	10	1090	360 kPa	8LB	515	279	11.0
11L-16	14	1285	506 kPa	8LB	813	279	12.7
11L-16	18	1460	360 kPa	8LB	838	279	13.4
11L-16	22	1750	440 kPa	8LB	838	279	12.7
11L-24	14	1815	506 kPa	8LB	838	279	13.7
14.5/75-16.1	18	1650	280 kPa	11LB	932	375	15.0

R4 STIL

TRA: R-4
TT/TL: TL
Applications: industrial vehicle

R4 STIL SUPER TIRE INDUSTRIAL LUG: excellent grip, wear and cut resistant compound, corner mud breakers for self-cleaning, reduced vibration and increased stability, deep under tread for puncture resistance, protected sidewall.

Sizes (8)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18.4-26(480/80-26)	12	4000	250 kPa	W16L	1420	678	26.7
18.4-26(480/80-26)	14	4370	250 kPa	W16L	1420	678	26.7
18.4-28(480/80-28)	12	3550	250 kPa	W16L	1490	678	27.0
18.4-28(480/80-28)	14	3875	300 kPa	W16L	1490	678	27.0
18.4-30(480/80-30)	12	4000	250 kPa	W16L	1490	678	27.0
18.4-36(480/80-30)	14	4500	300 kPa	W16L	1420	679	27.0
18.4-34(480/80-34)	12	4120	250 kPa	W16L	1620	679	28.7
18.4-34(480/80-34)	14	4600	250 kPa	W16L	1620	679	28.7

R4 ITL

TRA: R-4
TT/TL: TT/TL; TL
Applications: industrial vehicle

R4 ITL IND TRACTOR LUG: extra wide lugs with overlapping center for wear and roadability, heavy duty construction for durability and damage resistance, excellent grip.

Sizes (10)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
16.9-24	20	2960	220 kPa	W15L	1200	396	24.0
16.9-24	32	3250	260 kPa	W15L	1290	396	24.0
16.9-28	20	3075	220 kPa	W15L,W14L	1320	396	25.5
16.9-28	32	3450	260 kPa	W15L,W14L	1320	396	25.5
17.5L-24	20	2860	220 kPa	W15L	1240	445	25.0
17.5L-24	32	3335	260 kPa	W15L	1240	445	25.0
19.5L-24	20	3060	180 kPa	W13L,W16L,DW16A	1314	495	28.0
19.5L-24	32	3450	290 kPa	DW16A	1314	495	38.0
21L-24	20	3330	180 kPa	W14L,DW18A	1378	533	32.0
21L-24	32	4560	280 kPa	DW18A	1378	533	32.0

R4 PIB

TRA: R-4
TT/TL: TL
Applications: backhoe loader, industrial vehicle

R4 PIB PREMIUM INDUSTRIAL BACK: directional opposed lugs for self-cleaning and traction on loose soil and sand, long multi-angle lugs for wear and smooth ride, tight center bars for road-ability, deep tread lugs; best choice for backhoes and industrial tractors.

Sizes (8)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.9-24	12	2900	230 kPa	W13L,W13	1215	378	25.5
16.9-24	12	3150	230 kPa	W15L	1385	419	25.5
16.9-28	12	3450	280 kPa	W15L,W14L	1438	419	26.5
17.5-24	10	2900	220 kPa	W15L	1414	445	26.5
16.9-28	12	4000	230 kPa	DW16A	1478	457	27.0
18.5L-24	12	3450	230 kPa	DW18A	1314	495	27.0
21L-24	12	3875	230 kPa	DW18A	1378	533	28.0
21L-24	16	4500	280 kPa	DW18A	1378	533	28.0

R4 BOOMLIFT

TRA: R-4
TT/TL: TL

R4 BOOMLIFT: low soil compaction and flotation for a stable ride in soft terrain, reduced downtime and cost, dual sidewall construction against puncture and tear, wider footprint for load distribution, superior tread life and traction.

Sizes (9)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
355/55D625	14	3450	520 kPa	11.75	936	500	22.5
15-19.5	16	4135	600 kPa	11.75	994	397	25
15-19.5	16	4625	660 kPa	11.75	994	397	25
385/65D22.5	16	4935	600 kPa	11.75	1018	397	25
385/65D22.5	18	5580	600 kPa	13.00	1018	385	25
16-25	16	6980	600 kPa	11.75	1065	389	25
16-25	16	5580	600 kPa	13.00	1018	385	25
445/50D710	18	7380	560 kPa	W15	1189	445	25
445/50D710	20	7740	700 kPa	W15	1189	445	25

MS-IND

TT/TL: TT
Applications: industrial vehicle

MS-IND industrial tyre: special compound for anti-cutting and wear resistance, large pattern for grip, specially strengthened body with high load-bearing capacity, wide driving surface and smooth driving.

Sizes (27)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18X7-8	16	1665/1450	1090 kPa	4.33R	465	173	17
21X8-9	14	1900/1755	1090 kPa	6.00E	535	200	18
220X9-10	16	2810/2270	1090 kPa	6.50F	566	225	20
23X10-12	16	3220/2770	800 kPa	8.00G	597	254	20
23X12-12	20	3160	1090 kPa	8.00G	597	254	20
27X10-12	24	3770	1090 kPa	8.00G	620	252	23
4.00-8	8	765/630	930 kPa	3.00D	415	112	13
5.00-8	10	1130/970	1090 kPa	3.50D	470	137	14
6.00-9	10	1505/1275	860 kPa	4.00E	540	160	16
6.50-10	12	1895/1600	1090 kPa	5.00F	560	175	18
7.00-12	12	2315/2005	860 kPa	5.00S	676	190	18
7.00-12	14	2500/2190	1090 kPa	5.00S	676	190	18
7.50-15	20	5000	1090 kPa	7.50BD	735	250	20
28X9-15	14	3050/2575	970 kPa	7.00BD	706	210	19
7.00-15	12	2870/2420	860 kPa	5.5	750	200	20
7.00-15	14	3140/2655	1090 kPa	5.5	750	200	20
7.50-15	12	3015/2680	790 kPa	6.00G	780	215	20
7.50-16	16	3325	950 kPa	6.00G	806	215	20
8.25-15	14	2772/3185	830 kPa	6.50BD	840	235	20
300-15	20	6515/5790	950 kPa	3.00BD	840	300	24
9.00-20	14	5150/4385	760 kPa	7	1018	259	30
9.00-20	16	5925/4725	860 kPa	7	1018	259	30
10.00-20	16	6030/5090	790 kPa	7.5	1055	278	34
11.00-20	16	6405/5405	760 kPa	8	1085	293	34
12.00-20	20	7400/6225	1090 kPa	8.5	1125	315	38
12.00-24	20	6140	1090 kPa	8.5	1225	315	38
14.00-24	28	12350	1090 kPa	10	1343	375	38

Agricultural and implement

M-FLOAT

Construction: Radial
TT/TL: TL
Applications: trailer

Radial flotation implement tyre designed for agricultural tanker and trailer applications; steel belted casing and special rubber compound offers high resistance to punctures and field hazards.

Sizes (6)

Size	L/S index	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
560/45R22.5	152D	16.03	1076	543	18
560/60R22.5	165D	16.03	1244	543	18
660/50R26.5	171D	20.03	1385	613	20
650/50R26.5	177D	20.03	1389	645	20
710/50R26.5	170D	24.03	1385	717	20
750/60R26.5	181D	24.03	1675	754	20

R-1

TRA: R-1

Size table of R-1 pattern agricultural tyres, 5.00-12 to 23.1-26, with PR, rim, overall diameter, section width, load capacity (kg) and inflated pressure (kPa).

Sizes (43)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
5.00-12	PR 8	345	280 kPa	4.00E	590	145
5.50-17	PR 8	400	280 kPa	4.00E	750	138
6.00-12	PR 8	450	330 kPa	4.50E	640	165
6.00-14	PR 8	530	330 kPa	4.50E	690	165
6.00-16	PR 8	550	360 kPa	4.50E	745	165
6.50-16	PR 8	660	330 kPa	5.00E	765	180
7.50-16	PR 8	770	280 kPa	5.50F	810	205
7.50-20	PR 8	915	280 kPa	5.50F	910	205
8.3-20	PR 8	850	310 kPa	W7	895	210
8.3-24	PR 8	830	250 kPa	W7	995	210
8.5-20	PR 8	780	250 kPa	W7	875	195
9.5-16	PR 6	800	210 kPa	W8	860	240
9.5-20	PR 8	955	280 kPa	W8	950	240
9.5-24	PR 8	1110	280 kPa	W8	1050	240
9.5-28	PR 8	1185	280 kPa	W8	1140	240
9.5-32	PR 8	1260	280 kPa	W8	1250	240
11.2-20	PR 8	1065	240 kPa	W10	1005	285
11.2-24	PR 10	1380	300 kPa	W10	1105	285
11.2-28	PR 8	1305	240 kPa	W10	1205	285
11-32	PR 8	1600	140 kPa	W10	1360	305
12.4-24	PR 10	1640	290 kPa	W11	1160	315
12.4-28	PR 8	1510	230 kPa	W11	1260	315
13.6/12-38	PR 10	2215	250 kPa	W11	1565	345
13.6-20	PR 8	1400	160 kPa	W12	1060	345
13.6-24	PR 10	1790	250 kPa	W12	1210	345
13.6-28	PR 10	1910	250 kPa	W12	1310	345
14.9-24	PR 10	1990	230 kPa	W13	1265	378
14.9-26	PR 10	2055	230 kPa	W13	1315	378
14.9-28	PR 10	2120	230 kPa	W13	1365	378
14.9-30	PR 10	2190	230 kPa	W13	1415	378
15-24	PR 10	2800	280 kPa	DW14	1330	410
15.5-38	PR 10	2320	230 kPa	W14	1570	395
16.9-24	PR 10	2230	200 kPa	W15L	1335	430
16.9-28	PR 10	2380	200 kPa	W15L	1435	430
16.9-30	PR 12	2730	240 kPa	W15L	1485	430
16.9-34	PR 10	2605	200 kPa	W15L	1585	430
16.9-38	PR 10	2760	200 kPa	W15L	1685	429
18.4-26	PR 12	2985	230 kPa	DW16	1450	467
18.4-30	PR 12	3180	230 kPa	W16L	1550	467
18.4-34	PR 12	3375	230 kPa	W16L	1655	467
18.4-38	PR 12	3575	230 kPa	W16L	1755	467
20.8-38	PR 12	4000	200 kPa	W18L	1835	528
23.1-26	PR 12	3610	170 kPa	DW20	1605	597

MR-1, F-2(3RIB), F-2(4RIB), F2-8, TF-2, TH657, TH672

TRA: MR-1, F-2, F2-3, F2-8, TF-2

Size tables for MR-1 agricultural drive tyres (12.4-36 to 30.5L-32) and front/implement patterns F-2(3RIB), F-2(3/4RIB), TF-2, F2-3, TH657, TH672 (4.00-12 to 11.00-16).

Sizes (34)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
12.4-36	PR 12	1925	330 kPa	W11	1464	315
12.4-38	PR 12	1905	310 kPa	W12	1514	315
13.6-16	PR 8	1060	150 kPa	W11	1000	345
13.6-20	PR 8	1400	160 kPa	W12	1060	345
14.9-38	PR 14	2725	320 kPa	W13	1621	378
15.5-38	PR 10	2320	230 kPa	W14	1570	395
18.4-30	PR 12	3180	230 kPa	W16L	1550	467
18.4-34	PR 12	3375	230 kPa	W16L	1655	467
20.8-34	PR 12	3785	200 kPa	W18L	1735	528
20.8-42	PR 12	3750	190 kPa	W18L	1935	528
23.1-30	PR 14	4200	200 kPa	DW20	1705	587
24.5-32	PR 16	4500	210 kPa	DW21	1803	622
30.5L-32	PR 16	5000	180 kPa	DW27	1819	775
4.00-12	PR 4	250	340 kPa	3.00D	535	110
4.00-14	PR 6	315	450 kPa	3.00D	590	110
5.00-15	PR 6	465	420 kPa	4J	665	140
5.50-16	PR 6	525	370 kPa	4.00E	710	150
6.00-16	PR 8	675	450 kPa	4.00E	740	160
6.50-16	PR 8	735	420 kPa	4.50E	780	175
6.50-20	PR 8	865	420 kPa	5.00F	880	180
7.5L-15	PR 8	840	370 kPa	6LB	745	208
7.50-16	PR 8	870	370 kPa	5.50F	810	205
7.50-18	PR 8	945	370 kPa	5.50F	880	206
7.50-20	PR 8	1020	370 kPa	5.50F	910	205
9.00-16	PR 8	1080	310 kPa	6LB	880	235
9.5L-15	PR 8	930	310 kPa	8LB	780	240
11L-15	PR 8	1070	280 kPa	8LB	810	280
10.00-16	PR 10	1325	340 kPa	W8L	910	275
11.00-16	PR 10	1495	310 kPa	W10L	970	315
9.00-16	PR 8	1200	400 kPa	6.50 H	880	234
5.50-16	PR 8	625	420 kPa	4.00E	685	150
6.00-16	PR 8	675	450 kPa	4.00E	740	160
6.50-16	PR 10	975	530 kPa	4.50E	760	182
7.00-16	PR 12	1090	530 kPa	5.5	790	202

PR-1, R-2(1), R-2(2), R-1(IRRIGATION)

TRA: PR-1, R-2, R-1

Size table for PR-1 (6.00-12 to 20.8-38), R-2(1) (19.5L-24 to 28L-26) and R-2(2) (9.5-24 to 24.5-32) agricultural tyres.

Sizes (38)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
6.00-12	PR 6	425	270 kPa	4.50E	690	160
6.00-14	PR 6	450	250 kPa	4.50E	710	165
6.50-16	PR 6	565	250 kPa	5.00F	830	165
7.50-16	PR 6	750	300 kPa	5.50F	890	195
8.3-20	PR 8	1130	350 kPa	W7	950	210
8.3-24	PR 8	1275	330 kPa	W7	1050	210
9.5-24	PR 8	1475	290 kPa	W8	1150	240
11.2-24	PR 10	1800	310 kPa	W10	1205	285
11-32	PR 10	1400	250 kPa	W10	1460	305
12.4-24	PR 8	1980	230 kPa	W11	1245	315
12.4-28	PR 6	1785	200 kPa	W11	1315	315
13.6-24	PR 10	1790	250 kPa	W12	1246	345
13.6-38	PR 10	2780	250 kPa	W12	1710	345
14.9-24	PR 10	1990	230 kPa	W13	1410	378
14.9-26	PR 10	2040	230 kPa	W13	1460	378
14.9-28	PR 10	2150	230 kPa	W13	1510	378
14.9-30	PR 10	2190	230 kPa	W13	1560	378
16.9-28	PR 10	2540	230 kPa	W15L	1533	430
16.9-30	PR 10	2455	200 kPa	W15L	1585	430
16.9-34	PR 10	3385	220 kPa	W15L	1685	430
18.4-30	PR 12	3180	230 kPa	W16L	1597	467
18.4-38	PR 12	3575	180 kPa	W16L	1855	467
20.8-38	PR 12	4100	200 kPa	W18L	1972	528
19.5L-24	PR 12	2145	210 kPa	W18L	1383	495
23.1-26	PR 12	3610	210 kPa	W17	1383	497
23.1-26	PR 12	3610	170 kPa	DW20	1662	587
28L-26	PR 14	4745	170 kPa	DW25	1672	715
9.5-24	PR 8	1110	280 kPa	W8	1076	240
13.6-24	PR 10	1790	250 kPa	W12	1246	345
14.9-24	PR 14	2650	370 kPa	W13	1305	378
14.9-28	PR 14	2900	300 kPa	W13	1406	378
18.4-30	PR 12	2900	220 kPa	W16L	1599	467
18.4-34	PR 12	3000	220 kPa	W16L	1701	467
18.4-38	PR 12	3250	220 kPa	W16L	1802	467
20.8-38	PR 12	3550	190 kPa	W18L	1886	528
23.1-26	PR 16	4460	240 kPa	DW20	1661	587
23.1-30	PR 16	4200	200 kPa	W13	1829	610
24.5-32	PR 16	4500	210 kPa	DW21	1862	622

I-1, IMP100, I-3, RIB100, C2, R-1(IRRIGATION)

TRA: I-1, I-3, R-1

Implement tyre size tables for I-1, IMP100, I-3/RIB100 and C2 patterns, plus an Irrigation Tyre table for R-1 irrigation patterns.

Sizes (22)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
9.5L-15	PR 8	1120	300 kPa	8LB	767	241
10-15	PR 10	1425	240 kPa	W7	760	264
11L-14	PR 8	1120	250 kPa	8KB	752	279
11L-15	PR 8	1130	220 kPa	W8L	775	280
11L-16	PR 12	1510	360 kPa	W8L	803	279
12.5L-15	PR 12	1750	350 kPa	W10L	823	318
6.00-16	PR 6	685	275 kPa	4.00E	710	158
7.50-16	PR 10	1240	400 kPa	5.50F	785	203
10.5/80-18	PR 10	1935	370 kPa	9.00	885	274
7.00-12	PR 12	1050	390 kPa	5.00F	683	192
10.0/80-12	PR 8	1240	310 kPa	9.00	715	264
10.0/75-15.3	PR 10	1525	390 kPa	8.00	785	264
11.5/80-15.3	PR 12	2145	410 kPa	9.00	854	290
12.5/80-15.3	PR 14	1650	430 kPa	9.00	869	297
400/60-15.5	PR 16	2240	400 kPa	13.00	874	404
500/45-22.5	PR 16	2360	280 kPa	16.00	1022	503
500/50-17	PR 14	2240	280 kPa	16.00	932	503
12.00-18(340/70-18)	PR 12	1950	420 kPa	9.00V	1100	340
11.2-38	PR 10	1555	300 kPa	W10	1465	285
13.6-24	PR 10	1790	250 kPa	W12	1210	345
14.9-24	PR 10	1990	230 kPa	W13	1265	378
14.9-24	PR 10	1990	230 kPa	W13	1265	378

R-1M, R-4 (3), R-4NEW, TH900, TH101

TRA: R-1, R-4

Size tables for R-1M and R-4(3) (405/70-20 to 15.5/80-24), R-4(NEW) (12.5/80-18 to 18.4-28) and Turf Tyre patterns TH900 and TH101.

Sizes (8)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
405/70-20(16/70-20)	PR 14	2900	350 kPa	13	1075	410
405/70-24(16/70-24)	PR 14	3350	350 kPa	13	1175	410
15.5/80-24(400/80-24)	PR 12	2900	300 kPa	W13	1240	395
12.5/80-18	PR 12	2625	370 kPa	9	865	308
16.9-28	PR 12	3450	260 kPa	W15L	1410	429
18.4-28	PR 12	2985	230 kPa	DW16	1438	467
26*7.5-12	PR 4	370	180 kPa	5.50F	680	205
16.5/70-18	PR 14	3650	410 kPa	W14L	1030	395

LVGM; LVGH

Construction: Radial
TRA: L-4, E-4, L-5
Stars: **
TT/TL: TL
Applications: scraper

Exceptionally robust in massive conditions; excellent compromise of adhesion and traction.

Sizes (14)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
23.5R25	L-4	201/186	14900/9250	6.5/5.25 bar	19.00/2.5	1878	597	47
23.5R25	E-4	201/186	14900/9250	6.5/5.25 bar	19.00/2.5	1878	597	47
26.5R25	L-4	209/193	18500/11500	6.5/3.25 bar	22.00/3.0	1798	673	57
26.5R25	E-4	209/193	18500/11500	6.5/3.25 bar	22.00/3.0	1798	673	57
29.5R29	L-4	218/212	23000/16000	6.5/3.25 bar	25.00/3.5	2123	750	60
29.5R29	E-4	218/212	23000/16000	6.5/3.25 bar	25.00/3.5	2123	750	60
29.5R33	L-4	224/217	28000/17000	6.5/5.25 bar	28.00/3.5	2446	889	62.5
29.5R33	E-4	224/217	28000/17000	6.5/5.25 bar	28.00/3.5	2446	889	62.5
23.5R25	L-5	193	11500	6.5 bar	17.00/2.0	1548	521	72
26.5R25	L-5	201	14500	6.5 bar	19.50/2.5	1979	597	78
26.5R25	L-5	209	16500	6.5 bar	22.00/3.0	1798	673	87
29.5R25	L-5	216	28000	6.5 bar	25.00/3.5	1961	750	85
29.5R29	L-5	219	28000	6.5 bar	25.00/3.5	2023	750	93
35/65R33	L-5	224	28000	6.5 bar	28.00/3.5	2365	890	97

Solid, skid steer and special

M-SKID2

Construction: Bias (cross-ply)
TRA: L5S
TT/TL: TL
Applications: skid steer loader

All cross-ply construction with improved load performance and enhanced operator comfort; deep tread and special traction improve performance with excellent self-cleaning properties.

Sizes (8)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
5.70-12	8
21X8.00-12	8
27X8.50-15	10
23.5-8	10
12-16.5	12
14-17.5	14
15-19.5	14
445/65-22.5	18

M-SKID4

Construction: Bias (cross-ply)
TRA: L5S
TT/TL: TL
Applications: skid steer loader

All cross-ply construction with improved load performance and enhanced operator comfort; full-flat profile with self-cleaning stepped tread improves performance.

Sizes (4)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
10-16.5	10
12-16.5	12
14-17.5	14
15-19.5	14

MA601

Applications: wheel loader, material handler

Optimised compound gives protection against cut and puncture damages; reduced rolling resistance; wide profile and deep tread lugs for machine stability and traction.

Sizes (6)

Size	Load (kg)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5-25	14930 (static)	14.00/1.5	1340	440	135
20.5-25	16980 (static)	17.00/2.0	1489	520	155
23.5-25	21100 (static)	19.50/2.5	1610	595	180
26.5-25	27500 (static)	22.00/3.0	1730	650	195
29.5-25	32500 (static)	25.00/3.5	1870	740	180
35/65-33	43330 (static)	28.00/3.5	2030	850	275

MA902

Construction: Solid
Applications: wheel loader, material handler

Solid smooth tyre for the toughest uses in extreme environments; high loading capacity and high mileage on severe surfaces; smooth design increases damage resistance.

Sizes (4)

Size	Load (kg)	Rim	O.D. (mm)	S.W. (mm)
13.5-25	9500 (25 km/h)	14.00/1.5	1540	448
20.5-25	10500 (25 km/h)	17.00/2.0	1500	520
23.5-25	13000 (25 km/h)	19.50/2.5	1620	590
26.5-25	16000 (25 km/h)	22.00/3.0	1730	660

MA801

Construction: Solid
Applications: skid steer loader, wheeled excavator, wheel loader

Solid tyre designed to eliminate downtime in extreme duty uses such as waste and recycling; enhanced compound resists cutting and chunking; self-cleaning pattern and long tread life.

Sizes (8)

Size	Load (kg)	Rim	O.D. (mm)	S.W. (mm)
5.70-12	1300 (25 km/h)	4.00	570	146
23x8.5-12	1700 (25 km/h)	5.00	580	190
30x10-16	2200 (25 km/h)	6.0	760	240
33x12-16	3200 (25 km/h)	8.0	820	286
33x12-20	3000 (25 km/h)	8.0	830	285
36.5x14-20	4000 (25 km/h)	11.0	920	350
13.00-24	6800 (25 km/h)	8.5	1270	520
14.00-24	8000 (25 km/h)	8.5/10.0	1340	340

MA802

Applications: wheeled excavator

Designed to eliminate downtime in extreme duty uses such as waste and recycling; enhanced compound resists cutting and chunking; self-cleaning pattern and long tread life.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
11.00-14			6540 (25 km/h)		8.5	1240	304

TH800, TH808, TH818, TH828

Sand Tyre table for TH800/TH808/TH818/TH828 (14.00-20, 16.00-20TT).

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00-20	PR 18		4125 (50 km/h)	245 kPa	10.00W	1220	375
16.00-20TT	PR 16		5450 (50 km/h)	245 kPa	10.00W	1370	420

SKS-1, SKS-2, SKS-3

Applications: skid steer loader

Size tables for SKS-1 (10-16.5 to 23X8.5-12), SKS-2 (10-16.5, 12-16.5) and SKS-3 (10-16.5 to 14-17.5) patterns.

Sizes (13)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
10-16.5	PR 10	2135	520 kPa	8.25	773	264
12-16.5	PR 12	2865	550 kPa	9.75	831	307
14-17.5	PR 14	3875	550 kPa	10.5	921	349
15-19.5	PR 14	4565	485 kPa	11.75	1019	389
11L-16	PR 12	1250	440 kPa	8LB	808	279
23X8.5-12	PR 6	655	230 kPa	7.00I	574	213
10-16.5	PR 12	2375	620 kPa	8.25	795	264
12-16.5	PR 14	3075	620 kPa	9.75	852	307
10-16.5	PR 12	2375	620 kPa	8.25	815	264
12-16.5	PR 14	3075	620 kPa	9.75	869	307
11L-16	PR 12	1250	440 kPa	8LB	855	279
12.5/80-18	PR 12	2625	370 kPa	9	1027	308
14-17.5	PR 14	3875	550 kPa	10.5	962	349

SKS-4, SKS-5, SKS-6

Applications: skid steer loader

Size tables for SKS-4 (10-16.5, 12-16.5), SKS-5 (10-16.5 to 16.9-28) and SKS-6 (10-16.5, 12-16.5) patterns.

Sizes (8)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
10-16.5	PR 12	2375	620 kPa	8.25	795	264
12-16.5	PR 14	3075	620 kPa	9.75	852	307
10-16.5	PR 12	2375	620 kPa	8.25	815	264
12-16.5	PR 14	3075	620 kPa	9.75	869	307
12.5/80-18	PR 12	2625	370 kPa	9	1027	308
16.9-28	PR 12	3450	260 kPa	W15L	1410	429
10-16.5	PR 12	2375	620 kPa	8.25	795	264
12-16.5	PR 14	3075	620 kPa	9.75	852	307

R4 PREMIUM

TRA: R-4
TT/TL: TL; TT

Self-cleaning open tread design, extra large tapered lugs for traction in slippery conditions, reinforced dual sidewall for wear and cut resistance, heavy rim guard protecting bead and wheel flange, improved productivity.

Sizes (11)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
5.70-12	6	560	370 kPa	4.50-5.10	570	145	16.8
10-16.5	10	2245	510 kPa	8.25	746	264	17.3
12-16.5	12	3070	610 kPa	9.50	831	309	15.8
14-17.5	14	3875	910 kPa	10.50	921	360	23.8
15-19.5	16	4835	850 kPa	11.75	1020	389	28.8
23x8.50-12	8	865	460 kPa	7.00-9.00	574	213	15.8
27x8.50-15	10	1230	485 kPa	7.50	678	233	15.8
31x10.5-15	14	1530	460 kPa	W9	843	274	15.4
31x15.5-15	14	3380	460 kPa	W9	865	393	25.4
27x10.5-15	8	2320	413 kPa	8.50	686	273	21.4
36x13-15	16	6510	758 kPa	11.00	960	375	23.8

L4 DEEP BLOCK

TRA: L-4
TT/TL: TL

Reinforced sidewall for tread stability and penetration resistance; deep tread for long tread life with a center block tread that resists skid wear.

Sizes (8)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
26-16.5	10	2135	528 kPa	8.25	723	264	27.0
26-16.5	12	2375	620 kPa	8.25	723	264	27.0
12-16.5	12	2695	558 kPa	9.75	831	307	33.5
12-16.5	14	3075	620 kPa	9.75	831	307	33.5
12-16.5	16	3399	760 kPa	9.75	831	307	33.5
14-17.5	14	3575	558 kPa	10.50	921	349	37.5
14-17.5	16	4030	638 kPa	10.50	921	349	37.5
15-19.5	14	4965	485 kPa	11.75	1019	389	37.5

L5 XDT

TRA: L-5
TT/TL: TL

X'TRA DUTY TRACTIONAL: extra deep tread and extra thick sidewalls for durability and puncture resistance, carcass strength for extreme heavy load, exceptional traction and long wear, long life.

Sizes (8)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
10-16.5	10	1835	520 kPa	8.25	790	268	35.0
12-16.5	12	2865	550 kPa	9.75	835	307	35.5
12-14-17.5	14	3075	550 kPa	10.50	935	349	36.5
12-15/70-18	14	1825	425 kPa	W9	965	308	37.0
12-15/80-18	16	3540	490 kPa	W9	965	308	37.0
16.9-28	14	4440	300 kPa	W15	1410	450	38.0
23x8.50-15	8	575	450 kPa	7.00	574	213	28.0
27x8.50-15	10	1090	520 kPa	7.0 B	681	215	31.0

L5 XDD

TRA: L-5
TT/TL: TL

X'TRA DUTY DIRECTIONAL: extra deep tread and extra thick sidewalls for durability and puncture resistance, carcass strength for extreme heavy load, exceptional traction and long wear, long life.

Sizes (3)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
18-25.5	10	2135	520 kPa	8.25	790	218	35.0
19.5-25	12	2665	520 kPa	9.75	866	325	35.0
16-31.5	14	3275	520 kPa	11.00	962	366	35.5

L5 BRUTE

TRA: L-5
TT/TL: TL

L5 BRUTE TRACTIONAL: extra deep tread and thick sidewalls against punctures, rim guard against flats and rim flange damage, rugged lug design for grip, braking and stability with higher loads, exceptional treadwear.

Sizes (5)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
5.70-12	8	850	630 kPa	4.50	574	145	20.0
5.90-15	8	750	630 kPa	5.00	686	152	26.0
10-16.5	14	2075	725 kPa	8.25	785	270	42.0
12-16.5	14	3075	630 kPa	9.75	861	271	43.0
27x8.50-15	10	1465	550 kPa	7.00	686	221	33.5

L5 BRUTE DIRECTIONAL

TRA: L-5
TT/TL: TL

L5 BRUTE DIRECTIONAL: ultra deep tread and thick sidewalls against punctures, rim guard against flats and rim flange damage, rugged lug design for grip, braking and stability with higher loads, exceptional treadwear.

Sizes (3)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
10-16.5	14	2725	725 kPa	8.25	785	270	42.0
12-16.5	14	3075	630 kPa	9.75	861	315	43.0
14-17.5	16	3875	520 kPa	10.50	945	349	43.0

R4 SOLIDMAX

Construction: Solid
TRA: R-4
TT/TL: solid

R4 SOLIDMAX solid tyre: cut and abrasion resistant tread, extra deep pattern and wide tread cap for traction and passing performance, deep self-cleaning step lugs, softer ride.

Sizes (4)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
301016	-	2900	- kPa	6.50-16	754	236	40
301020	-	2900	- kPa	7.0-20	754	236	40
331220	-	4950	- kPa	8.5-20	837	280	42
331420	-	6850	- kPa	8.5-20	914	330	45

Compactor and grader

M-SNOW

Construction: All steel radial
TRA: G2, L2
Stars: **
TT/TL: TL
Applications: wheel loader, grader

All steel radial construction; high-tech casing reduces heat build-up; open and self cleaning tread pattern with separate tread blocks and multiple sipes for excellent traction.

Sizes (6)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5R25	G2	162A8	4750	4.5	14.00/1.5	1320	440	28
17.5R25	L2	182A2	8500	6.5	14.00/1.5	1320	440	28
20.5R25	G2	170A8	6000	4.5	17.00/2.0	1484	540	31
20.5R25	L2	193A2	11500	6.5	17.00/2.0	1484	540	31
23.5R25	G2	179A8	7750	4.5	19.50/2.5	1600	550	30
23.5R25	L2	201A2	14500	6.5	19.50/2.5	1600	550	30

MB720

Construction: Bias (cross-ply)
TRA: IND
TT/TL: TL
Applications: compactor

All cross-ply construction with improved load performance; tread pattern offers excellent traction and flotation.

Sizes (2)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
23.1-26	IND	153A6	3655	1.7	DW20	1500	595	16
23.1-26	IND	165A2	5150	2.0	DW20	1500	595	16

MB720S

Construction: Bias (cross-ply)
TRA: IND
TT/TL: TT
Applications: compactor

All cross-ply construction; smooth tread promotes even wear and reduced ground pressure for better compaction performance.

Sizes (1)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
11.00-20	IND	169A2	5800	8.25	8.00	1080	290	22

L4, L5A, L5, G2

TRA: L4, L5, G2

Size tables for L4 (17.5-25), L5A/L5 (17.5-25 to 26.5-25) and G2 (20.5/70-16, 16/70-20) patterns with max load at 10 km/h and inflation pressure.

Sizes (7)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
17.5-25	PR 16	7300	475 kPa	14.00/1.5	1400	445
17.5-25	PR 20	8250	575 kPa	14.00/1.5	1400	445
20.5-25	PR 24	10300	525 kPa	17.00/2.0	1550	520
23.5-25	PR 24	12500	475 kPa	19.50/2.5	1675	595
26.5-25	PR 28	15500	475 kPa	22.00/3.00	1800	675
20.5/70-16	PR 16	2850	350 kPa	8.5H	950	400
16/70-20	PR 14	5150	450 kPa	13	1070	410

G2/L2, G2/L2A, G2/L2C, G2/L2B

TRA: G2, L2
Applications: grader, wheel loader, excavator

Grader Loader Tyre tables for G2/L2, G2/L2A and G2/L2C patterns (13.00-24 to 23.5-25) and Excavator Tyre table for G2/L2B (9.00-20, 10.00-20).

Sizes (8)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)
13.00-24	PR 12	5600 (10 km/h)		8.00TG	1280	335
14.00-24	PR 16	7300 (10 km/h)		8.00TG	1350	360
15.5-25	PR 12	/ (10 km/h)		12.00/1.3	1275	395
17.5-25	PR 16	/ (10 km/h)		14.00/1.5	1350	445
20.5-25	PR 16	/ (10 km/h)		17.00/2.0	1490	520
23.5-25	PR 16	/ (10 km/h)		19.50/2.5	1615	595
9.00-20	PR 14	2575	770 kPa	7.0	1038	259
10.00-20	PR 16	3000	810 kPa	7.5	1073	278

G1; MLVN

Construction: Bias (cross-ply)
TRA: L-3, G-1, E-3, G-2, L-2
Stars: * / **
TT/TL: TT, TL
Applications: scraper, grader

G1 wear resistance tread design suitable for loaders, bulldozers and earth moving machinery; MLVN offers superior traction and non-directional pattern.

Sizes (11)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
17.5-25	L-3		6150/3650	3.5/2.25 bar	14.00/1.5	1350	445	26
17.5-25	G-1		6150/3650	3.5/2.25 bar	14.00/1.5	1350	445	26
20.5-25	E-3		8250/5450	3.5/2.75 bar	17.00/2.0	1490	520	28
20.5-25	G-1		8250/5450	3.5/2.75 bar	17.00/2.0	1490	520	28
23.5-25	L-3		9500/6150	3.2/2.25 bar	19.50/2.5	1615	595	33.5
23.5-25	G-1		9500/6150	3.2/2.25 bar	19.50/2.5	1615	595	33.5
26.5-25	E-3		15500/10000	4.75/3.5 bar	22.00/3.0	1750	675	39
26.5-25	L-3		15500/10000	4.75/3.5 bar	22.00/3.0	1750	675	39
13.00R24	G-2	146	3000	3.75 bar	8.00/1.4	1290	335	26.5
16.00R24	L-2	181/163	8250/4875	8.25/4.25 bar	10.00/1.7	1459	427	27
16.00R24	G-2	181/163	8250/4875	8.25/4.25 bar	10.00/1.7	1459	427	27

MVZS; LVHE

TRA: E-3
Stars: ***
TT/TL: TL; TT
Applications: mobile crane, compactor, rigid dump truck

MVZS: heat resistance compound and high speed durability, reduced rubber tension for better cut resistance, up to 10% additional tread volume. LVHE: extra deep tread and big pattern blocks, mining truck tires on rough condition.

Sizes (5)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00R24 (385/95R24)	E-2	170	6000	10	10.00W	1368	382	23
14.00R25 (385/95R25)	E-2	170	6000	10	10.00/1.5	1368	382	23
16.00R25 (445/95R25)	E-2	174/177	6700/7300	10	11.25/2.0	1493	432	28
12.00R24	E-3	156	4000	8.5	8.5	1225	315	30
12.00R24	E-3	161	4625	8.5	8.5	1225	315	30

MV6/MV6N

TRA: G-2, L-2
TT/TL: TL
Applications: ice and snow, wheel loader

Snow compound for SNOW&ICE road with excellent traction in snow condition; light construction for loader only; high speed durability.

Sizes (20)

Size	TRA	L/S index	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
14.00R24	G-2	175/153	6900/3650	10	10.00W	1352	373	23
14.00R24	L-2	175/153	6900/3650	10	10.00W	1352	373	23
14.00R25	E-2	170	6000	10	10.00/1.5	1352	373	23
15.5R25	L-2	176	7100	6.5	12.00/1.3	1277	394	25
15.5R25	E-2	160	4500	5.25	12.00/1.3	1277	394	25
16.00R25	E-2	174/177	6700/7300	7.0	11.25/2.0	1490	432	28
17.5R25	L-2	182	8500	6.5	14.00/1.5	1348	445	28
17.5R25	E-2	167	5450	5.25	14.00/1.5	1348	445	28
20.5R25	L-2	193	11500	6.5	17.00/2.0	1490	621	31
20.5R25	E-2	177	7300	5.25	17.00/2.0	1490	621	31
23.5R25	L-2	201	14500	6.5	19.50/2.5	1617	697	34
23.5R25	E-2	185	9250	5.25	19.50/2.5	1617	697	34
26.5R25	L-2	209	16000	6.5	22.00/3.0	1750	673	37
26.5R25	E-2	193	11500	5.25	22.00/3.0	1750	673	37
29.5R25	L-2	216	22400	6.5	25.00/3.5	1873	750	43.5
29.5R25	E-2	200	14000	5.25	25.00/3.5	1873	750	43.5
17.5R25	L-2	182	8500	6.5	14.00/1.5	1348	445	28
17.5R25	E-2	167	5450	5.25	14.00/1.5	1348	445	28
23.5R25	L-2	201	14500	6.5	19.50/2.5	1617	697	34
23.5R25	E-2	185	9250	5.25	19.50/2.5	1617	697	34

G2/L2 GRADERMAX; C1

TRA: G2, L2, C1
TT/TL: TL
Applications: grader, muddy ground

G2/L2 GRADERMAX and C1: deep directional patterns for traction and self-cleaning; wide tread for buoyancy and driving performance on muddy roads.

Sizes (13)

Size	TRA	Load (kg)	Pressure (bar)	Rim	O.D. (mm)	S.W. (mm)	T.D. (mm)
13.00-24	G2	2725	300 kPa	8.00TG	1210	355	25
13.00-24	L2	2725	300 kPa	8.00TG	1210	355	25
14.00-24	G2	3650	375 kPa	8.00TG	1360	369	25
14.00-24	L2	3650	375 kPa	8.00TG	1360	369	25
15.5-25	G2	2650	325 kPa	12.00/1.3	1275	395	24
15.5-25	L2	2650	325 kPa	12.00/1.3	1275	395	24
17.5-25	G2	3550	325 kPa	14.00/1.3	1350	445	29
17.5-25	L2	3550	325 kPa	14.00/1.3	1350	445	29
7.00-15	C1	1800	460 kPa	6	738	215	12
7.50-15	C1	2650	750 kPa	6	783	215	12
7.50-15	C1	2900	875 kPa	6	783	215	12
11.00-20	C1	5450	725 kPa	8	1660	293	16
13.00-20	C1	6000	950 kPa	8.5	1660	320	18

For a precise answer

What to include.

The more precise the request, the faster the right match.

Machine make and model
Tyre size and TRA code
Pattern, or the job site conditions
Quantity, single order or regular supply
Destination port and preferred Incoterm

Questions

Common questionsabout OTR tyres.

What does the TRA code on an OTR tyre mean?

It tells you the machine the tyre is designed for and its tread type. E is for earthmovers such as dump trucks and scrapers, L for loaders and dozers, G for graders and C for compactors, and the number gives the tread: 2 traction, 3 rock, 4 rock deep and 5 rock very deep.

What is the difference between radial and bias OTR tyres?

Radial tyres have steel cords running straight across from bead to bead, which gives a flexible sidewall, a stable footprint and lower heat build-up on longer hauls. Bias (cross-ply) tyres have plies laid at an angle, giving a stiffer, cut-resistant sidewall that suits short cycles and rough sites; the catalogue has both.

What do stars and PR mean on an OTR tyre?

They show the load strength of the casing: stars on radial tyres, ply rating (PR) on bias tyres. More stars or a higher ply rating means a higher load capacity at the rated inflation pressure.

How do I choose the right OTR tyre for my machine?

Start with the machine make and model and the tyre size, then choose the TRA code and pattern for the job site conditions and the load. Send these with the quantity and destination port, and the supplier confirms the match in writing.

How many OTR tyre patterns are in the catalogue?

130 patterns for mining, earthmoving, underground, port and industrial, agricultural and special machines, radial and bias. Each lists size, TRA code, load, rim and dimensions as typical values, and the full catalogue is available as a PDF.

Guides

Before you senda specification.

Get started

Which tyredo you need?

Free to ask, with no obligation. Nothing is shared with the other side before an NDA is signed. Prefer to talk? WhatsApp +971 52 662 1066 · Telegram · Admin@BGIBrokers.com. See our Privacy notice and Website terms.

Chat with BGI on WhatsApp

Have a photo of the label, part or nameplate? Send it on WhatsApp and we will build the specification for you.

Email: Admin@BGIBrokers.com
WhatsApp: +971 52 662 1066
Telegram: t.me/BGIBrokers
LinkedIn: linkedin.com/company/bgibrokers
Instagram: instagram.com/BGIBrokers

Enquiry type I am a supplier I am buying Something else

ProductProduct familyProduct

Quantity

Single lotRegular supply

Quantity, in your wordsDestination regionIncoterm

Are you the end buyer or an intermediary?

End buyerIntermediary

Contact Name Company Email Machine, tyre size, TRA code, quantity and destination

Off-the-road tyres,130 patterns, sizes on request.

How OTR tyres are coded.

All patterns and sizes.

Mining and earthmoving

Underground mining

Port, terminal and industrial

Agricultural and implement

Solid, skid steer and special

Compactor and grader

What to include.

Common questionsabout OTR tyres.

What does the TRA code on an OTR tyre mean?

What is the difference between radial and bias OTR tyres?

What do stars and PR mean on an OTR tyre?

How do I choose the right OTR tyre for my machine?

How many OTR tyre patterns are in the catalogue?

Before you senda specification.

OTR tyre sizes and TRA codes

How to inspect used trucks before shipment

Which tyredo you need?
